1. Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  2. 3X USB power delivery for greater compatibility and extra power for USB devices
  3. Ultra Durable 3 technology with 2 oz copper PCB for lower working temperature
  4. Revolution energy saving design with DES Advanced featuring hardware based Dynamic 6-Gear switching
  5. Supports 45nm Intel Core 2 multi-core processors with FSB 1600 MHz
  6. Natively support dual channel DDR3 2200+ for remarkable system performance
  7. 2 PCI-E 2.0 x16 graphics interface with ATI CrossFireX support for ultimate graphics performance
  8. Built-in TPM chip with 2048bits encryption to highest level digital data protection
  9. 100% 50,000 hours lifespan of Japanese solid capacitors design
  10. Patented DualBIOS with dual hardware BIOS protection
  11. Hardware Overvoltage Control IC provides more voltage control options on CPU, North bridge and memory
  12. Supports Dolby Home Theater audio to enjoy a rich surround sound experience
  13. Blu-ray playback supported by Blu-ray playback supported by high quality HD audio
  • Introduction


    The GA-EP45T-USB3P introduces revolutionary GIGABYTE Ultra Durable 3 technology featuring a 2 oz copper PCB to help reduce system temperature and dramatically enhance performance. Based on the Intel P45 chipset the GA-EP45T-USB3P delivers a record-setting 1600MHz FSB for the latest Intel Core 2 multi-core processors, and supports dual channel DDR3 memory at speeds of up to 2200MHz and even higher. The GA-EP45T-USB3P boasts dual PCI Express 2.0 VGA card slots for ATI CrossFireX™ support with ultra smooth 3D rendering and blazingly-fast frame rates. Additionally, the board incorporates GIGABYTE DES Advanced technology for industry leading energy saving and enhanced system efficiency.
  • Qualified for Windows® 7
    The motherboard qualified for WHQL (Windows Hardware Quality Labs) certification of Windows 7 from Microsoft®, setting the standard for future Windows 7 certified motherboards...more
  • Ultra Durable 3 – Copper Cooled Quality


    GIGABYTE Ultra Durable 3 series motherboards once again lead the motherboard industry for the highest quality and most innovative motherboard design. Featuring the industry’s first consumer desktop motherboard design to introduce 2 ounces of copper for both the Power and Ground layers, delivering a dramatically lower system temperature, improved energy efficiency and enhanced stability for overclocking.
    GIGABYTE Ultra Durable 3 motherboards are also equipped with the GIGABYTE Ultra Durable signature features including Japanese Solid Capacitors boasting an operational life time of more than 50,000 hours, Ferrite core chokes with higher energy efficiency compared to the commonly used iron core chokes and Lower RDS(on) MOSFETs that features a lower resistance, which reduces power consumption and heat generation. GIGABYTE Ultra Durable 3 series motherboards promise to provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games...more
    Enlarge View Enlarge View
  • Support USB 3.0
    The GIGABYTE motherboards support the latest generation SuperSpeed USB 3.0 technology made possible through an onboard USB3.0 host controller. With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users of long term use of their legacy USB 2.0 devices. The onboard SuperSpeed USB 3.0 technology also provides new power management features that include increased maximum bus power and device current draw to better accommodate power-hungry devices.
  • 3x USB Power Boost
    L'emploi de 3x USB Power Boost permet d'assurer stabilité et compatibilité optimale avec des périphériques tels que HDDs externes ou lecteurs optiques en leur assurant des sources d'énergies nécessaires à leur bon fonctionnement.

    (note) Seuls les ports frontaux supportent la technologie 3X USB Power


  • DDR3 2200+ Support
    Delivering native support for DDR3 memory up to 2200+MHz, GIGABYTE Ultra Durable 3 series motherboards allow users to easily reach higher memory frequencies at lower voltages; achieving higher memory performance with lower power consumption to run even the most memory intensive applications such as high-definition video and 3D games with ease.
    * Please refer "Memory Support List" for memory support information
  • Smart TPM - A smarter , better way to protect your data
    TPM function is optional due to different regional policy
    GIGABYTE Smart TPM provides the industry's highest level of data protection with 2048 bit hardware encryption. Smart TPM allows users to store their digital key on a USB thumb drive. In addition, Smart TPM allows users to lock the protected data remotely using a Bluetooth® enabled mobile phone.
    Note: GIGABYTE motherboards do not include a Bluetooth® receiver; the addition of a 3rd party Bluetooth receiver is required.


  • Dynamic Energy Saver Advanced
    GIGABYTE Dynamic Energy Saver Advanced provides better energy saving capabilities and enhanced system performance. GIGABYTE Dynamic Energy Saver Advanced is the world’s only motherboard energy saving technology with hardware-based Dynamic 6-Gear* Switching. With support for VRD 11.1, GIGABYTE’s DES Advanced allows the motherboard to switch to 1 Gear phase switching during idle, allowing for a dramatic increase in power savings.

    GIGABYTE has also retooled Dynamic Energy Saver to allow overclockers to experience the benefits of multi-gear power phase switching while overclocking, providing ultra stable, ultra smooth overclocking performance.
    * The 6-Gear feature may vary by model. Gear 1 phase switching requires 45nm processors with PSI signal enabled.


  • Overclocking sans effort en un click !
    GIGABYTE quick boost propose 3 niveaux de performances pour votre cpu, en un simple click vous pourrez choisir le profil de votre choix et bénéficier d'un overclocking rapide et sans effort !
  • EasyTune6
    Logiciel de gestion et de tweaking de votre système
  • Hardware OverVoltage Control IC-- Enabling Extreme Overclocking
    GIGABYTE Hardware Overvoltage Control ICs featuring more voltage control options than before for the CPU North Bridge and memory. The overvoltage controllers also provide hardware linear real-time voltage control, which means there is no delay compared to the GPIO controller in past implementations. In addition, GIGABYTE’s Hardware Overvoltage Controller ICs also allow for much finer voltage control, allowing power users to adjust voltage in as little increments as 20mV for better overclocking performance.


  • DDualBIOS™ - Protection Double Bios
    DualBIOS™ - Protection Double Bios
  • ATI CrossFireX
    ATI® CrossFireX™ delivers the ultimate graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution.
  • Dolby Home Theater®
    Dolby Home Theater positionne chaque utilisateur au coeur de son environnement multimédia pour une expérience cinématographique unique.
  • Offre un son surround de qualité pour chacun de vos jeux, films ou fichier musical.
  • Détection / Configurations automatique de votre environnement
  • Condensateurs solides japonais - 50,000h
    GIGABYTE Ultra Durable motherboards are equipped with solid capacitors developed by leading Japanese manufacturers. With an average lifespan of 50,000 hours, these solid capacitors provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games...more


    * 50000 hours of work time is calculated at 85℃ ambient temperature.

    • * Les termes HDMI, interface multimédia haute définition HDMI et habillage commercial HDMI, et les logos HDMI sont des marques commerciales et des marques déposées de HDMI Licensing Administrator, Inc.
