HCI Server - AMD EPYC™ 7002/7001 - 2U 4-Node UP 4-Bay NVMe/SATA
- Supports 5G network infrastructure
- 2U 4-node front access server system for Edge Computing
- Single AMD EPYC™ 7002/7001 Series Processors per node
- 8-Channel DDR4 RDIMM/LRDIMM, 8 x DIMMs per node
- 8 x 1 Gb/s LAN ports via Intel® I350-AM2
- 4 x 2.5" Gen3 NVMe/SATA hot-swap bays
- 8 x M.2 slots with PCIe Gen3 x4 interface
- 4 x LP PCIe Gen4 x16 slots
- 4 x LP PCIe Gen3 x16 slots
- 4 x OCP 2.0 Gen3 x16 mezzanine slots
- Dual 1300 W 80 PLUS Platinum redundant power supplies
Ordering Numbers: 6NH242Z11MR-00-1*
仕様
Dimensions (WxHxD, mm)
2U 4-Node - Front access
440 x 87.5 x 475
440 x 87.5 x 475
Motherboard
MZ12-HD0
CPU
AMD EPYC™ 7002 Series Processors
AMD EPYC™ 7001 Series Processors
Single processor per node, cTDP up to 240 W
- At 30°C ambient, cTDP up to 280W
AMD EPYC™ 7001 Series Processors
Single processor per node, cTDP up to 240 W
- At 30°C ambient, cTDP up to 280W
Socket
4 x LGA 4094
Socket SP3
Socket SP3
Chipset
System on Chip
Memory
32 x DIMM slots
Support DDR4 RDIMM/LRDIMM
8-Channel memory per processor
Up to 3200 MT/s
Support DDR4 RDIMM/LRDIMM
8-Channel memory per processor
Up to 3200 MT/s
LAN
Front:
8 x 1 Gb/s LAN (4 x Intel® I350-AM2)
- Support NCSI function
4 x 10/100/1000 Mb/s Management LAN
8 x 1 Gb/s LAN (4 x Intel® I350-AM2)
- Support NCSI function
4 x 10/100/1000 Mb/s Management LAN
Video
Integrated in ASPEED® AST2500 x 4
- 4 x VGA ports
- 4 x VGA ports
Storage
Front hot-swap:
4 x 2.5" Gen3 NVMe/SATA
Internal M.2:
8 x M.2 (2242/2260/2280/22110), PCIe Gen3 x4
4 x 2.5" Gen3 NVMe/SATA
Internal M.2:
8 x M.2 (2242/2260/2280/22110), PCIe Gen3 x4
SAS
N/A
RAID
N/A
PCIe Expansion Slots
4 x LP x16 (Gen4 x16)
4 x LP x16 (Gen3 x16)
4 x OCP 2.0 mezzanine (Gen3 x16)(Type1, P1, P2, P3, P4)
- Support NCSI function
4 x LP x16 (Gen3 x16)
4 x OCP 2.0 mezzanine (Gen3 x16)(Type1, P1, P2, P3, P4)
- Support NCSI function
Front I/O
8 x USB 3.0 ports (Type-A)
4 x VGA ports
8 x RJ45 ports
4 x MLAN ports
4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
4 x ID LEDs
4 x VGA ports
8 x RJ45 ports
4 x MLAN ports
4 x Power buttons with LED
4 x ID buttons with LED
4 x Reset buttons
4 x System status LEDs
4 x ID LEDs
Rear I/O
N/A
Backplane Board
Speed and bandwidth:
PCIe Gen3 x4 or SATA 6 Gb/s
PCIe Gen3 x4 or SATA 6 Gb/s
Security Modules
1 x TPM header with SPI interface
- Optional TPM 2.0 kit: CTM010
- Optional TPM 2.0 kit: CTM010
Power Supply[#1]
Dual 1300 W 80 PLUS Platinum redundant power supplies
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
System Management
ASPEED® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface
GIGABYTE Management Console web interface
- Dashboard
- JAVA Based Serial Over LAN
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Citrix Hypervisor 8.1.0 or later
Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later
Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later
VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later
Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later
VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
OS Certifications
System Fans
1 x 40x40x28mm
3 x 80x80x38mm
3 x 80x80x38mm
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Weight
Net Weight: 19.8 kg
Gross Weight: 30.56 kg
Gross Weight: 30.56 kg
Packaging Dimensions
857 x 670 x 280 mm
Packaging Content
1 x H242-Z11
4 x CPU heatsinks
1 x 2-Section Rail kit
4 x CPU heatsinks
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NH242Z11MR-00-1*
- Motherboard: 9MZ12HD0NR-00*
- 2-Section Rail kit: 25HB2-AA6107-K0R
- Backplane board - CBPH043: 9CBPH043NR-00*
- CPU heatsink: 25ST1-44320J-A0R
- Fan module: 25ST2-44282D-D0R/25ST2-88382E-D0R
- Power supply: 25EP0-213006-F3S
Optional parts:
- M.2 expansion card - CMTP051: 9CMTP051NR-00*
- CMC kit: 6NH242Z13SR-00*
- M.2 heatsink kit: 6NH242Z17SR-00-100
- RMA packaging: 6NH242Z11SR-RMA-A100
- Motherboard: 9MZ12HD0NR-00*
- 2-Section Rail kit: 25HB2-AA6107-K0R
- Backplane board - CBPH043: 9CBPH043NR-00*
- CPU heatsink: 25ST1-44320J-A0R
- Fan module: 25ST2-44282D-D0R/25ST2-88382E-D0R
- Power supply: 25EP0-213006-F3S
Optional parts:
- M.2 expansion card - CMTP051: 9CMTP051NR-00*
- CMC kit: 6NH242Z13SR-00*
- M.2 heatsink kit: 6NH242Z17SR-00-100
- RMA packaging: 6NH242Z11SR-RMA-A100
[#1] Power cords are not included with server packages. Customers are responsible for selecting appropriate power cords from the optional accessories or contacting sales for customization.
[#2] All materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at any time without prior notice.
[#3] Advertised performance is based on maximum theoretical values as specified by the respective chipset vendors or standards organizations. Actual performance may vary depending on system configuration.
[#4] All trademarks and logos are the property of their respective owners.
