G492-Z51

Rev. 100Rev. A00

HPC/AI Server - AMD EPYC™ 7002 - 4U DP 10 x PCIe Gen4 GPUs (Broadcom solution)

AI AI Training AI Inference Visual Computing HPC

NVIDIA-Certified Systems™ - Data Center Servers
Supports up to 10 x Dual slot Gen4 GPUs
Dual AMD EPYC™ 7002 Series Processors
8-Channel DDR4 RDIMM/LRDIMM, 32 x DIMMs
2 x 10Gb/s LAN ports via Intel^® X550-AT2
8 x 3.5"/2.5" Gen3 NVMe/SATA/SAS hot-swappable bays
4 x 3.5"/2.5" SATA/SAS hot-swappable bays
10 x FHFL PCIe Gen4 x16 slots for GPUs
3 x LP PCIe Gen4 x16 slots
1 x OCP 3.0 Gen4 x16 slot on the rear side
Triple 2200W 80 PLUS Platinum redundant power supply

Compare

Save

Quote

Overview
Specifications
Support
Related Resources
Where to Buy

Specifications

Dimensions (WxHxD, mm)

4U
448 x 176 x 880

Motherboard

MZ52-G40

CPU

AMD EPYC™ 7002 Series Processors
Dual processor, 7nm technology
Up to 64 cores, 128 threads per processor
cTDP up to 280W

Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Compatible with AMD EPYC™ 7001 Series Processors (single processor only)

Socket

2 x LGA 4094
Socket SP3

Chipset

System on Chip

Memory

32 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
Memory speed: Up to 3200*/2933 MT/s

*Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.

LAN

Front side:
2 x 10Gb/s LAN ports (1 x Intel^® X550-AT2)
Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^® AST2500
- 1 x VGA port

Storage

Front side:
8 x 3.5"/2.5" Gen3 NVMe/SATA/SAS hot-swappable bays
- (4 x NVMe from CPU_0, 4 x NVMe from CPU_1)

4 x 3.5"/2.5" SATA/SAS hot-swappable bays

SAS card is required for SAS devices support

SAS

Depends on SAS add-in cards

RAID

N/A

Expansion Slots

10 x PCIe x16 (Gen4 x16) FHFL slots, from PEX88096, for GPUs
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_1
1 x PCIe x16 (Gen4 x16) low-profile slot on the rear side, from CPU_0

1 x OCP 3.0 slot with PCIe Gen4 x16 on the rear side, from CPU_1

- System is validated for population with a uniform GPU model.
- Support is not provided for mixed GPU populations.

Internal I/O

1 x TPM header

Front I/O

2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED

Rear I/O

N/A

Backplane Board

Speed and bandwidth:
PCIe Gen3 x4 or SAS 12Gb/s or SATA 6Gb/s

TPM

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply^[#1]

Triple 2200W 80 PLUS Platinum redundant power supply

AC Input:
- 100-127V~/ 14A, 47-63Hz
- 200-240V~/ 12.6A, 47-63Hz

DC Input: (Only for China)
- 240Vdc/ 12.6A

DC Output:
- Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.12V/ 178.1A
+12Vsb/ 3.5A

Note: The system power supply requires C19 power cord.

System Management

Aspeed^® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage/Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Citrix Hypervisor 8.1.0 or later

Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later

Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later

VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019

System Fans

4 x 40x40x28mm (25,000rpm)
12 x 60x60x38mm (21,700rpm)

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Note: Please contact Technical Support for more information about optimized GPU operating temperature.

Weight

Net Weight: 35 kg

Packaging Dimensions

1109 x 609 x 606 mm

Packaging Content

1 x G492-Z51
2 x CPU fansinks
8 x GPU power cables (CPU 8pin, 100mm)
2 x GPU power cables (CPU 8pin, 300mm)
1 x L-shape Rail kit

Part Numbers

- Barebone package: 6NG492Z51MR-00-1*
- Motherboard: 9MZ52G40NR-00
- L-shape Rail kit: 25HB2-A96100-K0R
- CPU fansink: 12SF2-01A067-00R
- Front panel board - CFPG015: 9CFPG015NR-00
- Backplane board - CBP20C2: 9CBP20C2NR-00
- Fan module: 6NG481HAASR-00-100
- GPU power cable (CPU 8pin, 100mm): 25CRI-100303-B0R
- GPU power cable (CPU 8pin, 300mm): 25CRI-300307-B0R
- Power supply: 25EP0-222008-D0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- RMA packaging: 6NG492Z51SR-RMA-A100

[#1] Power cords are not included with server packages. Customers are responsible for selecting appropriate power cords from the optional accessories or contacting sales for customization.

[#2] All materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at any time without prior notice.

[#3] Advertised performance is based on maximum theoretical values as specified by the respective chipset vendors or standards organizations. Actual performance may vary depending on system configuration.

[#4] All trademarks and logos are the property of their respective owners.
