GB-SIOPS-J1900Legacy | Software updates supported
OPS Digital Signage
- Intel® Celeron® J1900 processor
- Intel HD Graphics
- 1 x GbE LAN port (Realtek RTL8111G)
- Realtek ALC283 audio controller
- 1 x 2.5" HDD/SDD bay
Specifications
Operating Properties
Operating temperature: 0°C to 45°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 60°C
Non-operating humidity: 0%-95% (non-condensing)
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 60°C
Non-operating humidity: 0%-95% (non-condensing)
CPU
Intel Celeron J1900
2.0GHz
4 cores 4 threads
2MB L2 cache
10W TDP
2.0GHz
4 cores 4 threads
2MB L2 cache
10W TDP
Socket
1 x BGA 1170
Memory
2 x SO-DIMM DDR3L slots
Up to 8GB
1.35V 1333MHz
Up to 8GB
1.35V 1333MHz
LAN
1 x GbE LAN port (Realtek RTL8111G)
Video
Intel HD Graphics
Max. resolution 2560 x 1440 @ 60Hz
Max. resolution 2560 x 1440 @ 60Hz
Audio
Realtek ALC283 controller
SATA
1 x SATA II 3Gb/s port
Expansion Slots
2 x Full-size Mini-PCIe slot
Rear I/O
1 x 80-pin JAE TX25 OPS connector
OS Supported
Windows Embedded 7
Windows 7 64bit
Windows 8.1 64bit
Windows 7 64bit
Windows 8.1 64bit
Power Supply
Power delivery through 80-pin JAE TX25 OPS connector
Packaging Content
1 x Mini-PCIe card bracket with 2 x screws
1 x Mini-PCIe screw
2 x HDD screws
1 x Mini-PCIe screw
2 x HDD screws
Ordering Information
5 pieces carton:
- Includes WiFi card (AW-NB159H) - 362x333x242mm
- 9BSIOPS1MS‐SI‐242
8 pieces carton:
- No WiFi card - 588x319x214mm
- 6BSIOPS1NS‐SI‐231
- Includes WiFi card (AW-NB159H) - 362x333x242mm
- 9BSIOPS1MS‐SI‐242
8 pieces carton:
- No WiFi card - 588x319x214mm
- 6BSIOPS1NS‐SI‐231
Storage
1 x 2.5" HDD/SSD bay, SATA II 3Gb/s
Front I/O
2 x WiFi antenna slots
1 x RJ45
2 x USB 2.0
1 x DisplayPort
1 x Power button
1 x Reset button
1 x Mic-In
1 x Line-Out
1 x RJ45
2 x USB 2.0
1 x DisplayPort
1 x Power button
1 x Reset button
1 x Mic-In
1 x Line-Out
System Fans
Active fan
Dimension
180 x 119 x 30 mm (WxDxH)
Motherboard
MZBAYOP-SI
Weight
750g
