  1. Supports AMD Phenom/ Athlon series processors
  2. Dual Channel DDR2 1066 for remarkable system performance
  3. Built-in 128MB DDR3 1333MHz SidePort Memory
  4. Integrated ATI Radeon HD3300 graphics (DirectX10)
  5. Ultimate graphics performance with dual PCI-E 2.0 x16 interface with ATI CrossFireX/ Hybrid CrossFireX support
  6. Features high speed Gigabit Ethernet and IEEE1394
  7. High quality 106dB SNR ALC889A HD audio
  8. Supports Dolby Home Theater audio to create a stunning surround sound listening experience.
  9. Integrated HDMI/ DVI interface with HDCP
  10. Patented DualBIOS with dual hardware BIOS protection
  11. All Japanese manufactured solid capacitors
* Whether 1066 MHz memory speed is supported depends on the CPU being used, please refer "Memory Support List" for memory support information.
  • Get Ready to Unleash the Power of AMD 6-Core CPU
    GIGABYTE's AMD motherboards are ready to support the new generation of AMD Phenom™II X 6 processors, delivering the very best platform for multitasking, multimedia and high performance gaming.
  • Introduction
    The GA-MA790GP-DS4H is GIGABYTE’s next generation, high performance platform based on the new AMD 790GX Chipset and support for the new AMD Phenom™ quad-core processors, with the latest AM2+ platform support, integrated DDR2 1066 memory controller, HyperTransport™ 3.0 technology links and 128-bit Floating Point Units. In addition, GA-MA790GP-DS4H features with innovative S features, further providing reliable and user friendly computing and reaching the maximum system performance easily via personalized software settings. GIGABYTE S series motherboards, the champion’s choice for AMD AM2+ platform!
  • Supports next generation of 45nm AMD AM3 CPU
    This motherboard designs with Split Power Plane, 4+1 phase VRM to support AMD the latest 45nm AM3 Phenom™II/ Athlon™II processors, delivering the great performance enchantment to system and ultimate scalability hardware expending.
  • The Industry's Leading All-Solid Capacitor motherboard Design
    To ensure a longer for systems in daily operation and boost system stability under extreme conditions, this platform adopts cutting-edge Conductive Polymer Aluminum Solid Capacitors from the world's leading vendors. With these high-quality components, users can take advantage of better electronic conductivity and excellent heat resistance for enhanced system durability.
  • AMD 790GX Chipset
    The AMD 790GX Chipset is the system logic of the latest AM2+ (HyperTransport 3.0) platform from AMD that enables its next generation Phenom™ processors. The AMD 790GX chipset integrated ATI Radeon™ HD 3300-based graphics architecture. This unique combination of Integrated Graphics Processor (IGP) creates a single motherboard featuring a world-class DX10, Shader Model 4.0 graphics, ATI Avivo™ Technology, and brand-new ATI Hybrid Graphics Technology and AMD UVD (Unified Video Decoder) Technology for faster and smoother game-play, a high quality video processing engine for advance quality of video and DVD playback.
  • EC AOD-ACC Support
    EC AOD-ACC is described as Embedded Controller for AMD OverDrive- Advanced Clock Calibration, which is the newest feature comes from AMD SB750 southbridge chip, destined for use AMD 790GX chipset, is set to allow AMD Phenom™ X4 Black Edition CPUs to be overclocked through AMD OverDrive™ utility further than was previously possible.
    * Please be noticed that GIGABYTE's product warranty does not cover damages caused by overclocking.
  • AMD OverDrive Support
    The AMD OverDrive™ utility provides high-end users the ability to maximize the capability, flexibility, and adjustability of the platforms utilizing AMD processors, sockets, and chipsets.
    * For enabling EC AOD-ACC technology, AMD OverDrive™ utility must be the version of 2.1.1 or later.
    * Regarding AMD OverDrive™ utility, please visit AMD official website for details:
    http://game.amd.com/us-en/drivers_overdrive.aspx Or click here for downloading beta version.
  • AMD Phenom™ processors
    The leading-edge performance and unparallel technology of AMD AM2+ Phenom™ processors have built its strength on the well-known AMD64 framework which consisted next generation of HyperTransport 3.0 Technology, and integrated DDR2 1066 memory controller, and 128-bit Floating Point Units. The AMD Phenom™ processors are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments to offer significant performance boosts and provides an overall more energy efficient platform.
  • پشتیبانی از حافظه DDR2 1066 دو کاناله
    Experience the advanced technology of DDR2 1066* memory, featuring faster speeds and higher data bandwidth, which delivers superior performance for the most demanding applications.
    * Whether 1066 MHz memory speed is supported depends on the CPU being used, please refer "Memory Support List" for memory support information.
  • Built-in 128MB DDR3 SidePort Memory
    Through the built-in 128MB DDR3 1333MHz SidePort memory to accelerate 3D performance enhanced up to an additional 10~15%.
  • 3‎D Graphics Performance Upgrade- up to 3DMark 2006 2800 marks!!
    The 3DMark 2006 is a benchmark software which is from Futuremark Corporation and generally used on analyzing a PC performance of DirectX® 3D visualization, especially a valuable guideline for gaming users as reference.
    • Hardware equipment required: [CPU] AMD Phenom 9850(2.5GHz), [Memory] DDR2 1066(1GBx2), [OS] Windows Vista 32-bit.
    • Software equipment required: [Benchmark] 3DMark 2006, [Resolution] 1280x1024x32 (no AA, no AF, 32bpp).
  • PCI-E 2.‎0 Graphics Interface
    PCI-E 2.0 doubles the bus standard's bandwidth from 2.5 Gbit/s to 5 Gbit/s, meaning a x32 connector can transfer data at up to 16 GB/s in each direction. PCI-E 2.0 also features improvements to the point-to-point data transfer protocol and its software architecture.
  • ATI Hybrid Graphics Technology support
    Experience the advanced ATI Hybrid Graphics Technology, which is including ATI Hybrid CrossFireX™, ATI SurroundView™, and ATI PowerPlay™. With combination of onboard GPU and a single VGA card’s GPU*, ATI Hybrid CrossFireX™ can bring remarkable display performance on AMD platform, and also further to increase your overall system value. ATI SurroundView™ allows multiple monitors support at once and also ATI PowerPlay™ enables power saving profiles to help reduce power consumption and further resulting in reduced system temperatures and fan noise.
    * Please use ATI Hybrid CrossFireX certified VGA card (i.e., ATI Radeon HD 2400, 3400 series).
    ** ATI Hybrid CrossFireX current only supports Windows Vista.
  • ATI CrossFireX™ support
    With support for latest ATI CrossFireX™ technology, GIGABYTE pushes the envelope once again by delivering highly optimized performance and flexibility demanded for power users and extreme gaming enthusiasts. Designed to provide unmatched multi-GPU support with dual PCI-E connectivity, the GA-MA790GP-DS4H allows users to take advantage of the ultra smooth 3D rendering, blazing-fast frame rates and enhanced visual quality possible.
  • رابط HDMI
    HDMI (High Definition Multimedia Interface) درگاهی است که امکان انتقال اطلاعات تصویری بیش از 5Gb در ثانیه را همراه با صدای با کیفیت بسیار بالا تنها از طریق یک کابل فراهم می‌کند. با وجود این درگاه امکان بازگشایی کردن و انتقال داده های صوتی با کیفیت بالا و تصاویر دیجیتالی با کیفیت 1080P به صورت غیر فشرده در روی یک کابل فراهم شده است بدون آن که کیفیت صدا و تصویر بر اثر تبدیل دیجیتال به آنالوگ کاهش پیدا کند. به علاوه اینکه HDMI با HDCP (محافظ محتوای دیجیتال در پهنای باند بالا) سازگار است. همچنین قادر به پخش Blu-ray/HD DVD و دیگر محتواهای رسانه ای محافظت شده می باشد.
  • Dolby Home Theater® - Enjoy a Rich Home Theater Surround Sound Experience
    Dolby Home Theater places listeners in the middle of the action, giving their PCs a powerful set of tools to deliver a cinema-style experience in vivid surround sound.
    • Delivers vivid surround sound for music, movies, and games, using two to eight speakers or any set of headphones
    • Designed to automatically deliver the best possible listening experience
  • ALC889A Enables a Superior Audio Experience

    Excellent Audio Performance
    High-performance DAC (Digital-Analog Converter) with 106 dB Signal-to-Noise ratio playback quality, designed especially for Windows Vista Premium PCs.



    Blu-ray/HD DVD Full Rate Audio Support
    The ALC889A enables high quality Full Rate Lossless Audio for content protected media and support for both Blu-ray and HD DVD formats for an exhilarating home theater entertainment experience.

    7.1+2 Channel High Definition Output
    The ALC889A provides support for 7.1 sound playback, plus 2 channels of independent stereo output (multiple streaming) through the front panel stereo outputs.
  • بایوس دوگانه انحصاری با حفاظت بایوس دوگانه سخت افزاری
    بایوس دوگانه یکی از تکنولوژی های انحصاری گیگابایت است که به صورت خودکار در زمان خرابی احتمالی بایوس اصلی اطلاعات را بازیابی می کند و از پاک شدن آنها جلوگیری می کند. بواسطه وجود دو ROM بایوس فیزیکی مجتمع آنبرد، تکنولوژی بایوس دوگانه گیگابایت می تواند به سرعت و به راحتی اطلاعات بایوس صدمه دیده را بازیابی کند و یا اطلاعات را از بایوس ویروسی شده به بایوس جایگزین انتقال دهد.
  • اتصال LAN گیگابیت
    رابط شبکه گیگابیت ارائه دهنده یک اتصال LAN پر سرعت با سرعت انتقال داده برابر با 1000Mb/s است که یک نسل جدید در پهنای باند اتصال ها به شمار می رود. اتصال LAN گیگابیت یک گزینه مناسب برای اتصال اینترنتی یکپارچه مثل محتویات صوتی و تصویری جریانی به شمار می رود.
  • IEEE1394 motherboard
    This motherboard with IEEE1394 FireWire interface from Texas Instruments (TI). With the transfer speed up to 400Mb/s, the new generation IEEE1394 interface further enhances PC connectivity with consumer electronics audio/video (A/V) appliances, and storage peripherals.
  • CrossFire
    With support for latest ATI CrossFireX™ technology, GIGABYTE pushes the envelope once again by delivering highly optimized performance and flexibility demanded by power users and extreme gaming enthusiasts. Designed to provide unmatched multi-GPU support with dual PCI Express connectivity, the GA-MA790GP-DS4H allows users to take advantage of the ultra smooth 3D rendering, blazing-fast frame rates and enhanced visual quality possible with a dual graphics card solution.
  • Speed
    The Speed compliant motherboards of GIGABYTE S-series provide intelligent over-clocking and over-voltage software settings through both hardware and software design...more
  • Smart
    The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!...more
  • Safe
    Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!...more
  • AMD Live Ready
    AMD Live Ready Requirement compliant.
  • Windows Vista Premium Logo Certified
    Windows Vista Premium promises to deliver a streamlined computing experience designed to fundamentally change how users view, find and organize their digital information. With GIGABYTE AM2+/ AM2 solutions enabling support for Vista Premium, GIGABYTE offers a fresh and unique desktop experience that will be more informative, intuitive and completely new...more
* کلیه موارد ارایه شده در این صفحه تنها مربوط به نوع مرجع می باشد.‎ گیگابایت حق تغییر یا تجدید نظر محتویات را در هر لحظه و بدون اطلاع قبلی دارد.‎
* کارایی ارایه شده بر اساس مقادیر حداکثر نظری رابط است که توسط فروشنده چیپ ست یا سازمان هایی که مشخصات رابط را تعیین کردند، ارائه شده است.‎ کارایی واقعی ممکن است بنا بر پیکربندی سیستم متفاوت باشد.‎
* کلیه لوگو ها و آرم های ثبت شده تحت مالکیت مالکین مربوطه آن ها قرار دارد.‎
* با توجه به معماری استاندارد رایانه های شخصی، مقدار مشخصی از حافظه جهت استفاده درونی سیستم درنظر گرفته می شود و طبیعتا مقدار واقعی حافظه سیستم کم تر از مقدار اظهار شده خواهد بود.‎
