• Supports new generation of AMD Phenom™ II X6 processors
  • Ultra Durable 3 Technology with copper cooled quality for lower working temperature
  • Revolution energy saving design with Easy Energy Saver technology
  • Supports AMD Phenom™/ Athlon™ series processors
  • Dual Channel DDR2 1200+ for remarkable system performance
  • Integrated ATI Radeon HD3200 graphics (DirectX10)
  • 2 PCI-E 2.0 x16 interface with ATI Hybrid CrossFireX support for ultimate graphics performance
  • Blu-ray playback supported by high quality 106dB SNR ALC889A HD audio
  • Supports Dolby Home Theater audio to enjoy a rich surround sound experience
  • Integrated HDMI/ DVI interface for Full HD 1080 Blu-ray playback with HDCP
  • Patented DualBIOS with dual hardware BIOS protection
  • 100% 50,000 hours lifespan of Japanese solid capacitors design
* DDR2 1200+ is supported with combination of AM2+ processors and qualified memory modules, please refer "Memory Support List" for detail memory support information.
  • Get Ready to Unleash the Power of AMD 6-Core CPU
    GIGABYTE's AMD motherboards are ready to support the new generation of AMD Phenom™II X 6 processors, delivering the very best platform for multitasking, multimedia and high performance gaming.
  • Introduction


    GA-MA78LMT-S2 offers high performance platform based on AMD 760G chipset, it is integrated ATI Radeon HD 3000 (DX10) graphics engine and supports AMD AM3 Phenom II/ Phenom/ Athlon processors, HyperTransport™ 3.0 technology links, DDR2 memory, PCI Express 2.0 graphics interface and so on. With the innovative GIGABYTE Easy Energy Saver technology, GA-MA78LMT-S2 is able to provide user friendly computing, reach the maximum system performance easily while still able to save the power and environment in real life at the same time.
  • Supports next generation of 45nm AMD AM3 CPU
    This motherboard designs with Split Power Plane, 4+1 phase VRM to support AMD the latest 45nm AM3 Phenom™II/ Athlon™II processors, delivering the great performance enchantment to system and ultimate scalability hardware expending.
  • AMD 780G Graphics Performance- up to 3DMark 2006 2000 marks!!
    The 3DMark 2006 is a benchmark software which is from Futuremark Corporation and generally used on analyzing a PC performance of DirectX® 3D visualization, especially a valuable guideline for gaming users as reference.
    • Hardware equipment required: [CPU] AMD Phenom 9600(2.2GHz), [Memory] DDR2 1066(1GBx2), [OS] Windows Vista 32-bit.
    • Software equipment required: [Benchmark] 3DMark 2006, [Resolution] 1280x1024x32 (no AA, no AF, 32bpp).
    * 2000+ marks in 3DMark06 was achieved by overclocking.
    * Please be aware that GIGABYTE's product warranty does not cover damages caused by overclocking.
  • ATI Hybrid Graphics Technology support
    ด้วยประสิทธิภาพของ ATI Hybrid Graphics Technology ที่มีการใส่เทคโนโลยี ATI Hybrid CrossFireX™, ATI SurroundView™, และ ATI PowerPlay™.ลงบนตัว GPU ที่บอร์ด ทำให้เพิ่มประสิทธิภาพการทำงานของระบบสูงขึ้น .
    * Please use ATI Hybrid CrossFireX certified DX11 VGA card (i.e., ATI Radeon HD 5450, etc.)
  • Ultra Durable 3 – Classic

    เมนบอร์ดบอร์ด GIGABYTE Ultra Durable 3 Classic มาพร้อมฟีเจอร์ 2 ounces copper PCB, ให้อายุการทำงานเฉลี่ยที่ยาวนานถึง 50,000 ชั่วโมงด้วย Solid Capacitors คุณภาพสูงจากประเทศญี่ปุ่น, ปกป้องระบบเสียหายด้วย GIGABYTE patented DualBIOS technology, มาเธอบอร์ดที่มีเทคโนโลยี Ultra Durable 3 Classic จะช่วยให้ระบบมีเสถียรภาพที่น่าเชื่อถือ, พร้อมให้พลังงานได้เต็มเปี่ยม และ ให้อายุการทำงานยืนยาว ซึ่งเป็นสิ่งจำเป็นสำหรับ High-End Processors, Components ที่มีความสำคัญต่อระบบ ตลอดจนอุปกรณ์ที่มีความร้อนสูงอื่นๆ นับเป็นส่วนประกอบหลักที่สำคัญที่สุดของการเพิ่มประสิทธิภาพของระบบ สำหรับการทำงานร่วมกับแอพลิเคชันและระบบเกมความเร็วสูงในปัจจุบัน
  • Supports Dual Channel DDR2 1200+
    Delivering native support for DDR2 memory up to 1200MHz, GIGABYTE motherboards allow users to easily reach higher memory frequencies at lower voltages; achieving higher memory performance with lower power consumption to run even the most memory intensive applications such as high-definition video and 3D games with ease.
    * DDR2 1200+ is supported with combination of AM3/ AM2+ processors and qualified memory modules, please refer "Memory Support List" for detail memory support information.
  • EasyTune6
    GIGABYTE ได้ออกแบบ EasyTune6 ทำให้คุณสามารถปรับแต่งค่าต่างๆ ในระบบฮาร์ดแวร์ได้ง่ายขึ้นและมีประสิทธิภาพสูง เช่น การ overclock
  • DualBIOS™ - Patented Dual Hardware BIOS Protection
    DualBIOS™ is a GIGABYTE patented technology that automatically recovers BIOS data when main BIOS has crashed or failed. Featuring 2 physical BIOS ROMs integrated onboard, GIGABYTE DualBIOS™ allows quick and seamless recovery from BIOS damage or failure due to viruses or improper BIOS updating.
  • HDMI 1.3* certification, support Full HD 1080P
    HDMI is able to provide up to 5Gb/s video transmitting bandwidth and multi-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. GA-MA78LMT-US2H has obtained the latest HDMI 1.3* certification, able to support Full HD 1080p multi-media and HDCP (High-bandwidth Digital Content Protection) which allowing Blu-ray/ HD DVD and other protected contents playback.
    * HDMI 1.3 certified in video spec only.
  • Dolby Home Theater® - Enjoy a Rich Home Theater Surround Sound Experience
    Delivers vivid surround sound for music, movies, and games, using two to eight speakers or any set of headphones.
  • ALC889A Enables a Superior Audio Experience

    Excellent Audio Performance
    High-performance DAC (Digital-Analog Converter) with 106 dB Signal-to-Noise ratio playback quality, designed especially for Windows Vista Premium PCs.



    Blu-ray/HD DVD Full Rate Audio Support
    The ALC889A enables high quality Full Rate Lossless Audio for content protected media and support for both Blu-ray and HD DVD formats for an exhilarating home theater entertainment experience.

    7.1+2 Channel High Definition Output
    The ALC889A provides support for 7.1 sound playback, plus 2 channels of independent stereo output (multiple streaming) through the front panel stereo outputs.
  • GIGABYTE innovative technology- Easy Energy Saver
    GIGABYTE Easy Energy Saver เป็นฟีเจอร์ที่ได้รับการออกแบบมาเป็นพิเศษ สำหรับช่วยจัดการระบบประหยัดพลังงาน สามารถปรับแต่งเพิ่มลดพลังของ CPU ได้, สามารถควบคุมระบบจัดการพลังงานได้อย่างมีเสถียรภาพ มีความเข้ากันได้ กับแพลตฟอร์ม AMD ปลอดปล่อยพลังได้อย่างเต็มที่ พร้อมการประหยัดพลังงานควบคู่กันไป เพื่อประสิทธิภาพที่ดียิ่งกว่า.
  • Windows Vista Premium Logo Certified
    Windows Vista Premium จะส่งมอบประสบการณ์ในการใช้งานเครื่องคอมพิวเตอร์ที่ยอดเยี่ยม ออกแบบมาเพื่อเปลี่ยนมุมมอง และค้นหา จัดการข้อมูลดิจิตอลที่มีคุณภาพ ผ่านโซลูชั่น P965/G965/946/945 สำหรับ Vista Premium, GIGABYTE ได้พยายามนำเสนอประสบการณ์ของเดสก์ ท็อปพีซีที่ดีที่สุด ใช้งานง่ายและเป็นระบบปฏิบัติการใหม่ล่าสุด....more
  • 50,000 Hours Japanese Solid Capacitors
    เมนบอร์ด GIGABYTE ทุกรุ่นที่มีเทคโนโลยี Ultra Durable จะได้รับการออกแบบด้วย Solid Capacitors คุณภาพสูงที่ได้รับการพัฒนาจากประเทศญี่ปุ่น ซึ่งโดยเฉลี่ยของอายุการทำงานของ Solid Capacitors จะมีอายุการทำงานที่ยืนยาวกว่า 50,000 ชั่วโมงจึงให้ความน่าเชื่อถือในการทำงานที่สูง พร้อมให้พละกำลังในการทำงานที่ยอดเยี่ยม นับเป็นตัวเก็บประจุไฟฟ้ารุ่นใหม่ที่ให้เสถียรภาพในการทำงานที่ดีมาก และกำลังเป็นที่ต้องการของอุตสาหกรรมในขณะนี้ เพราะสามารถรองรับการทำงานร่วมกับโพรเซสเซอร์ระดับไฮเอนต์ และส่วนประกอบอื่นๆ ที่มีความร้อนสูงได้เป็นอย่างดี นับเป็นส่วนประกอบหลักที่สำคัญที่สุดของการเพิ่มประสิทธิภาพระบบ ที่ต้องทำงานร่วมกับแอพลิเคชันและระบบเกมความเร็วสูงในปัจจุบัน...

* คำว่ำ HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress และโลโก้ HDMI เป็ นเคร ื่องหมำยกำรค้ำหรือเครื่องหมำยกำรค้ำจดทะเบียนของ HDMI Licensing Administrator, Inc.
* ข้อมูลเบื้องต้นมีไว้สำหรับอ้างอิงเท่านั้น GIGABYTE ขอสงวนสิทธิ์ในการปรับเปลี่ยนหรือแก้ไขเนื้อหาได้ตลอดเวลาโดยไม่ต้องแจ้งให้ทราบล่วงหน้า
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิปเซ็ตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
