GA-586SG

Teknik ÖzelliklerDestekHaberler/ÖdüllerWhere to Buy

Teknik Özellikler

  • İşlemci
    1. Intel Pentium® /MMX ™/Overdrive ® Processor 90-233MHz
    2. AMD®K5/K6® (PR166 to 300) Processor Support
    3. Cyrix®/IBM® 6x86/6x86L/MX? PR 150 - 266 MHz Processor Support
    4. ZIF Socket 7 for Future Processor Support
    5. (Auto Detect & Setup Intel Pentium ® MMX ® Processor,Cyrix® /IBM ® 6x86,6x86L, AMD ® K5)
  • Yongaseti
    1. SIS 5591
    2. Winbond 83877 I/O chip (1Mb/Sec)
  • Bellek
    1. System Memory
      1. Supports 8MB to 768MB DRAM Size
      2. 4 x 72-pins 5V SIMM and 2 168-pins 3.3V DIMM sockets support
      3. 5V and 3.3V DRAM Mixable
      4. Use combination of 8/16/128/256 MB 3.3V SDRAM and/or 4/8/16/32/64 MB SIMM module DRAM with Fast Page Mode or EDO DRAM.(see table in the manual for the mix combinations)
      5. Supports ECC Type DIMM Module (72bits)
    2. Cache memory
      1. 512KB PB SRAM onboard (512KB MAX)
  • Genişleme Yuvaları
    1. 1 x AGP Slot (Supports 1x an 2x mode)
    2. 4 x PCI 32-bit slots, supports 33MHz, & PCI 2.1 Compliant
    3. 2 x ISA 16-bit slots
  • Dahili G/Ç Bağlantı Noktaları
    1. AT Keyboard & PS/2 Mouse support
    2. 1x Floppy port (360KB-2.88MB)
    3. 2x Serial port (16550 high-speed)
    4. 1x Parallel port (EPP/ECP)
    5. 2x USB ports (USB cable optional with additional fee)
  • BIOS
    1. 1Mbit (128KB) FLASH RAM
    2. Award PCI BIOS with green, plug and play, INT 13 (>8.4GB), ACPI for PC98/Win98 Compliant & Anti-Virus Functions
    3. LS120, ZIP, & CD-ROM Bootable
    4. Auto Detect & Report System health Information
  • Driver
    1. SiS Ultra DMA/33 Bus Master IDE Driver (optional)
  • Other Features
    1. SIMM and DIMM mixable
    2. 75MHz/83MHz System Bus
    3. AGP Support
  • İşlemci
    1. Intel Pentium® /MMX ™/Overdrive ® Processor 90-233MHz
    2. AMD®K5/K6® (PR166 to 300) Processor Support
    3. Cyrix®/IBM® 6x86/6x86L/MX? PR 150 - 266 MHz Processor Support
    4. ZIF Socket 7 for Future Processor Support
    5. (Auto Detect & Setup Intel Pentium ® MMX ® Processor,Cyrix® /IBM ® 6x86,6x86L, AMD ® K5)
  • Yongaseti
    1. SIS 5591
    2. Winbond 83877 I/O chip (1Mb/Sec)
  • Bellek
    1. System Memory
      1. Supports 8MB to 768MB DRAM Size
      2. 4 x 72-pins 5V SIMM and 2 168-pins 3.3V DIMM sockets support
      3. 5V and 3.3V DRAM Mixable
      4. Use combination of 8/16/128/256 MB 3.3V SDRAM and/or 4/8/16/32/64 MB SIMM module DRAM with Fast Page Mode or EDO DRAM.(see table in the manual for the mix combinations)
      5. Supports ECC Type DIMM Module (72bits)
    2. Cache memory
      1. 512KB PB SRAM onboard (512KB MAX)
  • Genişleme Yuvaları
    1. 1 x AGP Slot (Supports 1x an 2x mode)
    2. 4 x PCI 32-bit slots, supports 33MHz, & PCI 2.1 Compliant
    3. 2 x ISA 16-bit slots
  • Dahili G/Ç Bağlantı Noktaları
    1. AT Keyboard & PS/2 Mouse support
    2. 1x Floppy port (360KB-2.88MB)
    3. 2x Serial port (16550 high-speed)
    4. 1x Parallel port (EPP/ECP)
    5. 2x USB ports (USB cable optional with additional fee)
  • BIOS
    1. 1Mbit (128KB) FLASH RAM
    2. Award PCI BIOS with green, plug and play, INT 13 (>8.4GB), ACPI for PC98/Win98 Compliant & Anti-Virus Functions
    3. LS120, ZIP, & CD-ROM Bootable
    4. Auto Detect & Report System health Information
  • Driver
    1. SiS Ultra DMA/33 Bus Master IDE Driver (optional)
  • Other Features
    1. SIMM and DIMM mixable
    2. 75MHz/83MHz System Bus
    3. AGP Support

* HDMI, HDMI High-Definition Multimedia Interface terimleri, HDMI Ticari takdim şekli ve HDMI Logoları HDMI Licensing Administrator, Inc.’nin ticari markaları veya tescilli ticari markalarıdır.
* Burada sağlanan tüm materyaller yalnızca referans içindir. GIGABYTE ürün teknik özelliklerinde ve ürün ile ilgili bilgilerde haber vermeden önce değişiklik yapma hakkını saklı tutar.
* Belirtilen performans, ara yüz özelliklerini belirleyen yonga seti üreticilerinden veya kurumlarından alınan maksimum teorik ara yüz değerlerine dayanır. Gerçek performans sistem üzerinde kullanılan bileşenlere göre değişkenlik gösterebilir.
* Tüm ticari markalar ve logolar, kendi sahiplerinin mülkiyetindedir.
* Standart PC mimarisi sınırlamaları nedeniyle, bellek miktarının bir kısmı sistem kullanımı için ayrılır ve gerçek bellek boyutu olması gerekenden daha az gösterilir.
