G492-ID0Legacy | Firmware updates supported

4U
448 x 175.2 x 945

MG62-G41

3rd Generation Intel^® Xeon^® Scalable Processors
Dual processor, 10nm technology
CPU TDP up to 270W

Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable

2 x LGA 4189
Socket P+

Intel^® C621A Chipset

32 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
RDIMM/LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHz

Front side:
2 x 10Gb/s BASE-T LAN ports (Intel^® X710-AT2)
1 x 10/100/1000 Management LAN

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM

Front side:
6 x 2.5" Gen4 NVMe/SATA hot-swappable bays*

*NVMe devices do not support hot-swappable function

N/A

Intel^® SATA RAID 0/1/10/5

NVIDIA HGX™ A100 8-GPU 40GB/80GB module

8 x PCIe x16 (Gen4 x16) low-profile slots on rear side, from PEX88096
1 x PCIe x16 (Gen4 x16) low-profile slot on front side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on front side, from CPU_1

2 x M.2 slots (CMTP062):
- M-key
- PCIe Gen4 x4, from PEX88096
- Supports 2242/2260/2280 cards

1 x TPM header
1 x VROC connector
2 x SATA DOM connectors
1 x Front panel header

2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x Storage activity LED

N/A

Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

3+1 3000W 80 PLUS Platinum redundant power supplies

AC Input:
- 115-127V~/ 14.2A, 50-60Hz
- 200-220V~/ 15.8A, 50-60Hz
- 220-240V~/ 14.9A, 50-60Hz

DC Input:
- 240Vdc/ 14A

DC Output:
- Max 1450W/ 115-127V~
+ 54V/ 26.6A
+ 12Vsb/ 3A
- Max 2900W/ 200-220V~
+ 54V/ 53.4A
+ 12Vsb/ 3A
- Max 3002.4W/ 220-240V~ or 240Vdc Input
+ 54V/ 55.6A
+ 12Vsb/ 3A

Note: The system power supply requires C19 power cord.

Aspeed^® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Windows Server 2016
Windows Server 2019
Windows Server 2022

Red Hat Enterprise Linux 7.9 (x64) or later
Red Hat Enterprise Linux 8.2 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later

SUSE Linux Enterprise Server 12 SP5 (x64) or later
SUSE Linux Enterprise Server 15 SP2 (x64) or later

Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update2 or later
VMware ESXi 8.0 or later

Citrix Hypervisor 8.2.0 or later

11 x 80x80x80mm (17,000rpm)
6 x 40x40x56mm (31,000rpm)
4 x 40x40x28mm (25,000rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Net Weight: 51.2 kg
Gross Weight: 103 kg

1176 x 782 x 822 mm

1 x G492-ID0
2 x CPU heatsinks
1 x L-shape Rail kit

- Barebone package with 40GB module: 6NG492ID0MR-00-1*
- Barebone package with 80GB module: 6NG492ID0MR-00-8*
- Motherboard: 9MG62G41NR-00
- L-shape Rail kit: 25HB2-A96101-K0R
- CPU heatsink: 25ST1-25320I-M1R
- Front panel board - CFPG430: 9CFPG430NR-00
- Backplane board - CBPG060: 9CBPG060NR-00
- Fan module (40x40x56mm): 25ST2-405629-N2R
- Fan module (40x40x28mm): 25ST2-44282D-D0R
- Fan module (80x80x80mm): 25ST2-808036-S1R/25ST2-808037-S1R
- M.2 extension board - CMTP062: 9CMTP062NR-00
- Power supply: 25EP0-230003-D0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- RMA packaging: 6NG492ID0SR-RMA-A100
