G492-ZD0
(rev. 100)

Discontinued

HPC/AI Server - AMD EPYC™ 7002 - 4U DP HGX™ A100 8-GPU
  • NVIDIA HGX™ A100 with 8 x SXM4 GPUs
  • NVIDIA® NVLink® and NVSwitch™ technology
  • Up to 600GB/s GPU to GPU interconnection
  • AMD EPYC™ 7002 Series processors
  • Dual processor, 7nm technology
  • 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs
  • 2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
  • 1 x Dedicated management port
  • 8 x 2.5" Gen4 NVMe/SATA hot-swappable bays
  • 8 x LP PCIe Gen4 x16 slots
  • 3+1 3000W 80 PLUS Platinum redundant power supplies
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

Dimensions (WxHxD, mm)
4U
448 x 175.2 x 900
Motherboard
MZ52-G40
CPU
AMD EPYC™ 7002 Series processors
Dual processor, 7nm technology
Up to 64-core, 128 threads per processor
cTDP up to 280W

Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable
Socket
2 x LGA 4094
Socket SP3
Chipset
System on Chip
Memory
32 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
Total up to 8TB 3DS/RDIMM/LRDIMM modules supported
Memory speed: Up to 3200*/2933 MHz

*Follow BIOS setting and memory QVL list if running 3200 Mhz with 2DPC
LAN
Front side:
2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
NCSI function supported

1 x 10/100/1000 Management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage
8 x 2.5" Gen4 NVMe/SATA hot-swappable bays
SAS
N/A
RAID
N/A
Peripheral Drives
N/A
Expansion Slots
NVIDIA HGX™ A100 8-GPU 40GB/80GB module

6 x PCIe x16 (Gen4 x16) low-profile slots, from PEX88096
1 x PCIe x16 (Gen4 x16) low-profile slot, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot, from CPU_1
Internal I/O
1 x TPM header
1 x Front panel header
Front I/O
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x Storage activity LED
Rear I/O
N/A
Backplane Board
Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Power Supply
3+1 3000W 80 PLUS Platinum redundant power supplies

AC Input:
- 115-127V~/ 14.2A, 50-60Hz
- 200-220V~/ 15.8A, 50-60Hz
- 220-240V~/ 14.9A, 50-60Hz

DC Input:
- 240Vdc/ 14A

DC Output:
- Max 1450W/ 115-127V~
+ 54V/ 26.6A
+ 12Vsb/ 3A
- Max 2900W/ 200-220V~
+ 54V/ 53.4A
+ 12Vsb/ 3A
- Max 3002.4W/ 220-240V~ or 240Vdc Input
+ 54V/ 55.6A
+ 12Vsb/ 3A

Note: The system power supply requires C19 type power cord.
System Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

  • Dashboard
  • HTML5 KVM
  • Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
  • Sensor Reading History Data
  • FRU Information
  • SEL Log in Linear Storage/Circular Storage Policy
  • Hardware Inventory
  • Fan Profile
  • System Firewall
  • Power Consumption
  • Power Control
  • LDAP / AD / RADIUS Support
  • Backup & Restore Configuration
  • Remote BIOS/BMC/CPLD Update
  • Event Log Filter
  • User Management
  • Media Redirection Settings
  • PAM Order Settings
  • SSL Settings
  • SMTP Settings
OS Compatibility
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019

Red Hat Enterprise Linux 7.6 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
Red Hat Enterprise Linux 9.0 (x64) or later

SUSE Linux Enterprise Server 12 SP4 (x64) or later
SUSE Linux Enterprise Server 15 SP1 (x64) or later

Ubuntu 16.04.6 LTS (x64) or later
Ubuntu 18.04.3 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later

VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later

Citrix Hypervisor 8.1.0 or later
System Fans
11 x 80x80x80mm (17,000rpm)
6 x 40x40x56mm (23,000rpm)
4 x 40x40x28mm (25,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 51.4 kg
Gross Weight: 101.6 kg
Packaging Dimensions
1176 x 782 x 822 mm
Packaging Content
1 x G492-ZD0
2 x CPU heatsinks
1 x L-shape Rail kit
Part Numbers
- Barebone package with 40GB module: 6NG492ZD0MR-00-1*
- Barebone package with 80GB module: 6NG492ZD0MR-00-8*
- Motherboard: 9MZ52G40NR-00
- L-shape Rail kit: 25HB2-A96101-K0R
- CPU heatsink: 25ST1-44320P-A3R
- Front panel board - CFPG110: 9CFPG110NR-00
- Backplane board - CBP2023: 9CBP2023NR-00
- Fan module: 25ST2-808036-S1R
- Fan module: 25ST2-808037-S1R
- Fan module: 25ST2-445627-D0R
- Fan module: 25ST2-44282D-D0R
- Power supply: 25EP0-230003-D0S

Optional parts:

- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- RMA packaging: 6NG492ZD0SR-RMA-A100
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SUPPORT

  • All
  • All
  • Windows Server 2019
  • Windows Server 2016 64bit
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.

What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.

  • All
  • All
  • Windows Server 2022
  • Windows Server 2019
  • Windows Server 2016 R2 64bit
  • Windows Server 2016 64bit
  • Windows Server 2012 R2 64bit
  • Windows Server 2012 64bit
  • Windows 10 64bit
  • VMware
  • Ubuntu
  • Linux CentOS
  • Linux
Utility
Description
Version
Size
Date
GSM CLI
Version : 2.1.75
147.86 MB
May 22, 2024
OS: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
Manual
Description
Version
Size
Date

RESOURCES

News
FRONT

  • img
    SKU
  • img
    I/O
  • img
    Storage
  • img
    Tool-less
The G492 is divided into two chambers to optimally cool components. The top 1U has the motherboard, CPUs, RAM, and storage. While the bottom 3U is dedicated to the NVIDIA HGX A100 8-GPU with maximum airflow.
TOP

  • img
    Tool-less
  • img
    CPU
  • img
    Memory
  • img
    Thermal
A simple latch at the top allows for easy opening and closing of cover
GPU

  • img
    Fans
  • img
    Air-Cooling
  • img
    Liquid-Cooling
A total of 21 fans were incorporated into the design to ensure optimal cooling for all components.
REAR

  • img
    Power Supply
  • img
    Fans
  • img
    PCIe Cage
Redundancy was built in the design with a 3 + 1 configuration. Should any PSU have issue, the redundant PSU will pick up the slack.
