Z690 UD DDR4 V2 (rev. 1.0)
Intel® Z690 Motherboard with 16*+1+2 Twin Hybrid Phases Digital Power Design, PCIe 5.0 Design, Ultra Performance VRM Heatsinks, 3 x PCIe 4.0 M.2 with Thermal Guard, 2.5 GbE LAN, Rear USB 3.2 Gen 2x2 Type-C®, Q-Flash Plus

  • Supports 12th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • 16*+1+2 Twin Hybrid Phases Digital Power Design with 90A Power Stage and Tantalum Polymer Capacitor​
  • Ultra Performance VRM Heatsinks
  • Fast 2.5 GbE LAN with Bandwidth Management
  • 3 x Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Enlarged Thermal Guard
  • SuperSpeed USB 3.2 Gen 2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

  • * 8+8 phases parallel power design, Power Stage maximum current capacity is based on VCORE Phase.
Z690 UD AX DDR4 V2 (rev. 1.0)
Intel® Z690 Motherboard with 16*+1+2 Twin Hybrid Phases Digital Power Design, PCIe 5.0 Design, Ultra Performance VRM Heatsinks, 3 x PCIe 4.0 M.2 with Thermal Guard, 2.5GbE LAN, WIFI6E 802.11ax, Rear USB 3.2 Gen 2x2 Type-C®, Q-Flash Plus

  • Supports 12th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • 16*+1+2 Twin Hybrid Phases Digital Power Design with 90A Power Stage and Tantalum Polymer Capacitor​
  • Ultra Performance VRM Heatsinks
  • Intel® WIFI6E 802.11ax 2T2R & BT5.2 with AERO Antenna
  • Fast 2.5 GbE LAN with Bandwidth Management
  • 3 x Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Enlarged Thermal Guard
  • SuperSpeed USB 3.2 Gen 2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

  • * 8+8 phases parallel power design, Power Stage maximum current capacity is based on VCORE Phase.
B660 GAMING X (rev. 1.0)
Intel® B660 GAMING Motherboard with 8+1+1 Phases Hybrid Digital VRM Design*, DDR5 XTREME MEMORY Design, Fully Covered Thermal Design, 3 x PCIe 4.0/3.0 M.2 with Thermal Guard, 2.5GbE Gaming LAN, Front USB 3.2 Gen 2 Type-C®, RGB FUSION 2.0, Q-Flash Plus​​

  • Supports 12th Gen Intel® Core™ Series Processors​​
  • Dual Channel Non-ECC Unbuffered DDR5, 4 DIMMs​​
  • 8+1+1 Hybrid Digital VRM Design with DrMOS*​​
  • DDR5 XTREME MEMORY Design with Shielded Memory Routing​
  • Fully Covered Thermal Design with High Coverage VRM Heatsinks​
  • Fast 2.5 GbE GAMING LAN with Bandwidth Management​​
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard​​
  • SuperSpeed USB 3.2 Gen 2 Type-C® delivers up to 10Gb/s transfer speeds​
  • Pre-installed IO Shield for easy and quick installation​
  • High Quality Audio Capacitors and Audio Noise Guard​
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips​​
  • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP​​
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card​​

*DrMOS adopted only on Vcore/Vgt phase counts. ​
B660 GAMING X AX DDR4 (rev. 1.0)
Intel® B660 GAMING Motherboard with 8+1+1 Phases Hybrid Digital VRM Design*, Fully Covered Thermal Design, 3 x PCIe 4.0/3.0 M.2 with Thermal Guard, 2.5GbE Gaming LAN, WIFI 6 802.11ax, Front USB 3.2 Gen 2 Type-C®, RGB FUSION 2.0, Q-Flash Plus​​

  • Supports 12th Gen Intel® Core™ Series Processors​​
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs​​
  • 8+1+1 Hybrid Digital VRM Design with DrMOS*​​
  • Fully Covered Thermal Design with High Coverage VRM Heatsinks​
  • WIFI 6 802.11ax 2T2R & BT5 with AERO Antenna​
  • Fast 2.5 GbE GAMING LAN with Bandwidth Management​​
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard
  • SuperSpeed USB 3.2 Gen 2 Type-C® delivers up to 10Gb/s transfer speeds​
  • Pre-installed IO Shield for easy and quick installation​
  • High Quality Audio Capacitors and Audio Noise Guard​
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips​​
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP​​
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card​​

*DrMOS adopted only on Vcore/Vgt phase counts. ​
B660 AORUS MASTER DDR4 (rev. 1.x)
Intel® B660 AORUS Motherboard with 16*+1+1 Twin Hybrid Phases Digital VRM Design, Fully Covered Thermal Design , 3 x PCIe 4.0*/3.0 M.2 with Enlarged Thermal Guard, Intel® 2.5GbE LAN, WIFI 6 802.11ax , 120dB Hi-Res Audio with WIMA, Rear USB 3.2 Gen 2x2 Type-C®, RGB FUSION 2.0, Q-Flash Plus

  • Supports 12th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • 16*+1+1 Twin Hybrid Digital VRM Design with 60A DrMOS
  • Shielded Memory Routing for Better Memory Overclocking
  • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
  • WIFI 6 802.11ax 2T2R & BT5 with AORUS Antenna
  • Amp-Up Audio with ALC1220 and WIMA Audio Capacitors
  • Blazing Fast Intel® 2.5GbE LAN with Bandwidth Management
  • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2 with Enlarged Thermal Guards
  • SuperSpeed USB 3.2 Gen 2x2 Type-C® delivers up to 20Gb/s transfer speeds
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

* Actual support may vary by CPU.
* 8+8 phases parallel power design
B660 AORUS MASTER (rev. 1.x)
Intel® B660 AORUS Motherboard with 16*+1+1 Twin Hybrid Phases Digital VRM Design , DDR5 XTREME MEMORY Design, Fully Covered Thermal Design , 3 x PCIe 4.0*/3.0 M.2 with Enlarged Thermal Guard, Intel® 2.5GbE LAN, WIFI 6 802.11ax , 120dB Hi-Res Audio with WIMA, Rear USB 3.2 Gen 2x2 Type-C®, RGB FUSION 2.0, Q-Flash Plus

  • Supports 12th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR5, 4 DIMMs
  • 16*+1+1 Twin Hybrid Digital VRM Design with 60A DrMOS
  • DDR5 XTREME MEMORY Design with Shielded Memory Routing
  • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
  • WIFI 6 802.11ax 2T2R & BT5 with AORUS Antenna
  • Amp-Up Audio with ALC1220 and WIMA Audio Capacitors
  • Blazing Fast Intel® 2.5GbE LAN with Bandwidth Management
  • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2 with Enlarged Thermal Guards
  • SuperSpeed USB 3.2 Gen 2x2 Type-C® delivers up to 20Gb/s transfer speeds
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

* Actual support may vary by CPU.
* 8+8 phases parallel power design
B660 GAMING X DDR4 (rev. 1.0)
Intel® B660 GAMING Motherboard with 8+1+1 Phases Hybrid Digital VRM Design*, Fully Covered Thermal Design, 3 x PCIe 4.0/3.0 M.2 with Thermal Guard, 2.5GbE Gaming LAN, Front USB 3.2 Gen 2 Type-C®, RGB FUSION 2.0, Q-Flash Plus​​

  • Supports 12th Gen Intel® Core™ Series Processors​​
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs​​
  • 8+1+1 Hybrid Digital VRM Design with DrMOS*​​
  • Fully Covered Thermal Design with High Coverage VRM Heatsinks​
  • Fast 2.5 GbE GAMING LAN with Bandwidth Management​​
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard​​
  • SuperSpeed USB 3.2 Gen 2 Type-C® delivers up to 10Gb/s transfer speeds​
  • Pre-installed IO Shield for easy and quick installation​
  • High Quality Audio Capacitors and Audio Noise Guard​
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips​​
  • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP​​
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card​​

*DrMOS adopted only on Vcore/Vgt phase counts. ​
Z690M AORUS ELITE DDR4 (rev. 1.0)
Intel® Z690 AORUS Motherboard with Direct 12+1+2 Phases Digital VRM Design, PCIe 5.0 Design, Fully Covered Thermal Design ,3 x PCIe 4.0 M.2 with Thermal Guard, Intel® 2.5GbE, Rear USB 3.2 Gen2x2 TYPE-C®, RGB FUSION 2.0, Q-Flash Plus

  • Supports 12th Gen Intel®  Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Direct 12+1+2 Digital VRM Design with 60A Power Stage* and Tantalum Polymer Capacitor
  • Shielded Memory Routing to Avoid Interference
  • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
  • Fast Intel® 2.5GbE LAN with Bandwidth Management
  • 3 x Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard
  • SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • Pre-installed IO Shield for easy and quick installation
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

* Power Stage maximum current capacity is based on VCORE Phase.
Z690M AORUS ELITE AX DDR4 (rev. 1.x)
Intel® Z690 AORUS Motherboard with Direct 12+1+2 Phases Digital VRM Design, PCIe 5.0 Design, Fully Covered Thermal Design , 3*PCIe 4.0 M.2 with Thermal Guard, Intel® 2.5GbE, WIFI6 802.11ax , Rear USB 3.2 Gen2x2 TYPE-C®, RGB FUSION 2.0, Q-Flash Plus

  • Supports 12th Gen Intel®  Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Direct 12+1+2 Digital VRM Design with 60A Power Stage* and Tantalum Polymer Capacitor
  • Shielded Memory Routing to Avoid Interference
  • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
  • WIFI6 802.11ax 2T2R & BT5 with AORUS Antenna
  • Fast Intel® 2.5GbE LAN with Bandwidth Management
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard
  • SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • Pre-installed IO Shield for easy and quick installation
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

* Power Stage maximum current capacity is based on VCORE Phase.
Z690 UD (rev. 1.0)
Intel® Z690 울트라 듀러블 메인보드: 다이렉트 16+1+2 페이즈 디지털 VRM 디자인, DDR5 XTREME MEMORY 탑재, PCIe 5.0 슬롯 내장, 완전 커버형 히트 싱크, PCIe 4.0 M.2 슬롯 3개(써멀 가드 포함), 2.5 GbE LAN, 후면 USB 3.2 Gen2x2 Type-C®, Q-Flash Plus

  • 12세대 Intel® Core™ 프로세서
  • 듀얼 채널 Non-ECC 버퍼링되지 않는 DDR 5, DIMM 4개 내장
  • SMD DIMM 및 쉴드 메모리 라우팅이 포함된 DDR5 XTREME MEMORY 설계
  • 디렉트 16+1+2페이즈 VRM 및 60A Power Stage* 및 탄탈륨 폴리머 커패시터
  • 초고효율 VRM 히트싱크
  • 대역폭 관리 소프트웨어를 지원하는 초고속 2.5GbE LAN
  • 3개의 초고속 NVMe PCIe 4.0 x4 M.2 슬롯 및 써멀 가드
  • 20Gb/s의 전송속도를 제공하는 초고속 USB 3.2 Gen2x2 TYPE-C® 내장
  • RGB 2.0를 탑재하여 멀티존 주소 지정 가능 LED 라이트 및 주소 지정 가능 LED 및 RGB LED 스트립 지원
  • 다수의 온도 센서를 내장하고 하이브리드 팬 헤더를 사용하며 FAN STOP 설계를 지원하는 혁신적인 Smart Fan 6
  • Q-Flash Plus: CPU와 메모리 및 그래픽카드를 설치하지 않아도 BIOS를 업데이트 가능
    *Power Stage의 최대 전류 용량은 VCORE 페이즈에 따라 다를 수 있습니다.
Z690 UD DDR4 (rev. 1.x)
Intel® Z690 Motherboard with 16*+1+2 Twin Hybrid Phases Digital Power Design, PCIe 5.0 Design, Ultra Performance VRM Heatsinks, 3 x PCIe 4.0 M.2 with Thermal Guard, 2.5 GbE LAN, Rear USB 3.2 Gen 2x2 Type-C®, Q-Flash Plus

  • Supports 12th Gen Intel® Core™ Series Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • 16*+1+2 Twin Hybrid Phases Digital Power Design with 60A Power Stage* and Tantalum Polymer Capacitor​
  • Ultra Performance VRM Heatsinks
  • Fast 2.5 GbE LAN with Bandwidth Management
  • 3 x Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Enlarged Thermal Guard
  • SuperSpeed USB 3.2 Gen 2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
  • RGB FUSION 2.0 supports Addressable LED & RGB LED Strips
  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

  • * 8+8 phases parallel power design
    * Power Stage maximum current capacity is based on VCORE Phase.
Z690 UD AX DDR4 (rev. 1.x)
Intel® Z690 울트라 듀러블 메인보드: 디렉트 16*+1+2페이즈 디지털 VRM 설계, PCIe 5.0 슬롯 내장, 완전 커버형 히트 싱크, PCIe 4.0 M.2 슬롯 3개(써멀 가드 포함), 2.5 GbE 게이밍 LAN, WIFI 6 802.11ax, 후면 USB 3.2 Gen2x2 Type-C® , Q-Flash Plus

  • 12세대 Intel® Core™ 프로세서
  • 듀얼 채널 Non-ECC 버퍼링되지 않는 DDR 4, DIMM 4개 내장
  • 16*+1+2 트윈 하이브리드 페이즈 디지털 파워 및 60A Power Stage* 및 탄탈륨 폴리머 커패시터
  • 초고효율 VRM 히트싱크
  • WIFI 6 802.11ax 2T2R & BT5 및 AERO 안테나 내장
  • 대역폭관리 소프트웨어를 지원하는 초고속 2.5GbE LAN
  • 3개의 초고속 NVMe PCIe 4.0 x4 M.2 슬롯 및 대형 써멀 가드
  • 20Gb/s의 전송속도를 제공하는 초고속 USB 3.2 Gen2x2 TYPE-C® 내장
  • RGB 2.0를 탑재하여 멀티존 주소 지정 가능 LED 라이트 및 주소 지정 가능 LED 및 RGB LED 스트립 지원
  • 다수의 온도 센서를 내장하고 하이브리드 팬 헤더를 사용하며 FAN STOP 설계를 지원하는 혁신적인 Smart Fan 6
  • Q-Flash Plus: CPU와 메모리 및 그래픽카드를 설치하지 않아도 BIOS를 업데이트 가능
    * 8+8 페이즈 병렬 전원 설계
    * Power Stage의 최대 전류 용량은 VCORE 페이즈에 따라 다를 수 있습니다.
