    GA-6KIEH-RH

    Discontinued

    Rev. 1.2
    Intel GME965 + ICH8M
    • Mini-ITX form factor addresses slim nettops, affordable all-in-one PCs, thin-client PCs.
    • Support one socket P Intel Core 2 Duo (45nm Penryn/ 65nm Merom) processor.
    • Built-in 5 SATA ports and support RAID 0/ 1/ 5/ 10
    • DVI-D/ HDMI/ YPbPr support full HD display.
    • Compact Flash card slot support boot up function.
    • 2 ports Gigabit Ethernet provide ample network bandwidth.

    SPECIFICATIONS

    Form Factor
    Mini-ITX
    170W x 170D (mm)
    CPU
    • Single socket P Intel Core 2 Duo (45nm Penryn/ 65nm Merom) processor
    • FSB 533/ 667/ 800MHz
    • TDP <35W
    Chipset
    • Intel GME965 chipset with Intel ICH8M
    Memory
    • 2 DDR2 DIMM socket
    • 2 channel native 533/ 667MHz up to 4GB
    LAN
    • 2 Gigabit LAN (Intel 82566DC + Intel 82573L)
    Video
    • Intel GMA X3100 (Intel GME965)
    Audio
    • 7.1+2 channel HD audio (Realtek ALC883)
    SATA
    • 4 ports SATA 3Gbps via Silicon Image SiI3124
    • 1 port SATA 3Gbps via Intel ICH8M
    IDE/ SCSI
    • 1 40pin IDE
    RAID
    • RAID 0/ 1/ 5/ 10
    Expansion Slots
    • 1 PCI
    • 1 Mini PCI
    • 1 Mini Card
    • 1 Compact Flash card slot support boot-up function
    Internal I/O
    • 2 COM
    • 4 USB
    Rear I/O
    • 3 Audio
    • 1 Component (YPbPr)
    • 1 DVI-D
    • 1 HDMI 1.3
    • 2 RJ45
    • 1 SPDIF out (Coaxial)
    • 4 USB
    • 1 VGA
    Power Supply
    • ATX power 20pin
    Ordering Information
    • 5M6KIEH00R-00-12B
    [#1] All materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at any time without prior notice.
    [#2] Advertised performance is based on maximum theoretical values as specified by the respective chipset vendors or standards organizations. Actual performance may vary depending on system configuration.
    [#3] All trademarks and logos are the property of their respective owners.

    SUPPORT

    • Do pobrania
      • Sterowniki
      • BIOS
      • Funkcja
    • Instrukcja
    • Support List
      • OS
      • QVL
    Online Support
    Sterowniki
    BIOS
    Funkcja
    OS
    QVL
    • All
    • All
    • Windows XP 64bit
    • Windows XP 32bit
    • Windows Vista 64bit
    • Windows Vista 32bit
    • Windows Server 2003 64bit
    • Windows Server 2003 32bit
    • Windows NT
    • Windows 2000
    AHCI
    AHCI
    Wersja
    Rozmiar
    Data
    1. ACHI driver
    Version : 6.10.0.6100
    0.29 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit,Windows Vista 32bit
    1. ACHI driver
    Version : 6.10.0.6100
    0.32 MB
    Oct 31, 2008
    Download
    OS: Windows XP 64bit,Windows Vista 64bit
    Audio
    Audio
    Wersja
    Rozmiar
    Data
    1. Audio driver
    2. For Windows operating system
    Version : 2.11.15.0
    43 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    1. Audio driver
    2. For Linux operating system
    Version : 5.01
    8.67 MB
    Oct 31, 2008
    Download
    Chipset Update Patch
    Chipset Update Patch
    Wersja
    Rozmiar
    Data
    1. Intel chipset driver
    Version : 8.3.1.1009
    2.01 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    ASF 2.0 Tools/iAMT Tools/System Tools/TPM Tools for Windows
    -
    35.44 MB
    Jan 23, 2009
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    Intel iAMT Driver for Windows XP/Vista
    -
    146.64 MB
    Jan 23, 2009
    Download
    OS: Windows XP 32bit,Windows XP 64bit
    Host RAID
    Host RAID
    Wersja
    Rozmiar
    Data
    1. Sil3114 RAID driver
    Version : 1.0.0.11
    0.4 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    LAN
    LAN
    Wersja
    Rozmiar
    Data
    1. Lan driver
    2. Vista 32bit operating system
    Version : 4.0.100.1124
    10.37 MB
    Oct 31, 2008
    Download
    OS: Windows Vista 32bit
    1. Lan driver
    2. Vista 64bit operating system
    Version : 4.0.100.1124
    11.4 MB
    Oct 31, 2008
    Download
    OS: Windows Vista 64bit
    1. Lan driver
    2. XP 32bit operating system
    Version : 4.0.100.1124
    10.95 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit
    1. Lan driver
    2. XP 64bit operating system
    Version : 4.0.100.1124
    11.96 MB
    Oct 31, 2008
    Download
    OS: Windows XP 64bit
    SAF-TE
    SAF-TE
    Wersja
    Rozmiar
    Data
    Sil 3114 SATA Non-RAID Driver for Windows
    -
    0.48 MB
    Jan 23, 2009
    Download
    OS: Windows 2000,Windows XP 32bit,Windows XP 64bit
    SATA RAID/AHCI
    SATA RAID/AHCI
    Wersja
    Rozmiar
    Data
    RAID Driver for Windows XP/Vista
    -
    0.84 MB
    Jan 23, 2009
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    SiI 3114 non-RAID serial ATA driver
    Version : 1.2.9.0
    0.36 MB
    Nov 03, 2009
    Download
    OS: Windows XP 64bit,Windows Vista 64bit,Windows Server 2003 64bit
    SiI 3114 non-RAID serial ATA driver as part of text mode setup on Windows NT, Windows 2000, Windows XP, Windows Server 2003, and Windows Vista.
    Version : 1.3.10.1
    0.12 MB
    Nov 03, 2009
    Download
    OS: Windows NT,Windows 2000,Windows XP 32bit,Windows Server 2003 32bit,Windows Vista 32bit
    SiI 3114 Serial ATA Soft RAID 5 driver as part of text mode setup on 64-bit versions of Windows XP and Windows Server 2003
    Version : 1.5.20.3
    0.24 MB
    Nov 03, 2009
    Download
    OS: Windows XP 64bit,Windows Server 2003 64bit
    SiI 3114 Serial ATA Soft RAID 5 driver as part of text mode setup on Windows 2000, Windows XP and Windows 2003
    Version : 1.5.20.3
    0.2 MB
    Nov 03, 2009
    Download
    OS: Windows 2000,Windows XP 32bit,Windows Server 2003 32bit
    SiI 3114 Serial ATA Soft RAID 5 driver as part of text mode setup on 64-bit versions of Windows XP and Windows Server 2003
    Version : 15151
    0.21 MB
    Nov 03, 2009
    Download
    OS: Windows XP 64bit,Windows Server 2003 64bit
    SiI 3114 Serial ATA Soft RAID 5 driver as part of text mode setup on Windows 2000, Windows XP and Windows 2003.
    Version : 15151
    0.17 MB
    Nov 03, 2009
    Download
    OS: Windows 2000,Windows XP 32bit,Windows Server 2003 32bit
    TPM
    TPM
    Wersja
    Rozmiar
    Data
    1. TPM driver
    Version : 3.0.1239.0
    92.57 MB
    Nov 03, 2008
    Download
    OS: Windows XP 32bit,Windows XP 64bit
    Intel iTPM Driver for Windows XP
    -
    71.67 MB
    Jan 23, 2009
    Download
    OS: Windows XP 32bit,Windows XP 64bit
    BIOS
    Opis
    Wersja
    Rozmiar
    Data
    1.Fixed Copy SD card date from SD to HDD will cause CPU0 full loading. 2.Supported "Processor Power Management" item in setup menu. 3.Support GBIA module to customize the Smart FAN control function. 4.Fixed fan speed display abnormal issue. 5.Support GBIA module to modify SMBIOS function.
    Version : F11
    0.81 MB
    Nov 05, 2010
    Download
    Hidden setup menu "Processor Power Management" item.
    Version : F4
    0.7 MB
    Mar 28, 2009
    Download
    Warning:
    Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.

    What is a BETA?
    BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
    • All
    • All
    • Windows XP 64bit
    • Windows XP 32bit
    • Windows Vista 64bit
    • Windows Vista 32bit
    Funkcja
    Opis
    Wersja
    Rozmiar
    Data
    Sil3114 RAID utility
    Version : v1.5.1.5.0
    31.73 MB
    Oct 31, 2008
    Download
    OS: Windows XP 32bit,Windows XP 64bit,Windows Vista 32bit,Windows Vista 64bit
    Instrukcja
    Opis
    Wersja
    Rozmiar
    Data
    Version : 1201
    0.55 MB
    Jul 22, 2010
    Download
    English
    Opis
    Wersja
    Rozmiar
    Data
    OS Support List
    Version : 1.0
    0.03 MB
    Sep 19, 2008
    Download
    Opis
    Wersja
    Rozmiar
    Data
    QVL Support List
    Version : 1.0
    0.02 MB
    Apr 08, 2009
    Download
    QVL for GA-6KIEH-RH (1.0)
