GA-H110MSTX-HD3-ZK(1.0)
GA-H110MSTX-HD3-ZK
* Product may vary based on local distribution.
  • Supports 7th/6th Generation Intel® Core™ Processor
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • Features USB 3.0 with USB Type-C™ Support
  • 1 x RS232 COM Port Support
  • M.2 Socket 1 Interface for WIFI+BT Module Support
  • M.2 Socket 3 Interface for SATA Mode SSD Support
  • Support 2 x 2.5 inch SATA3 HDD
  • Rear Panel DisplayPort, HDMI 1.4, D-Sub Ports for Multi-Display Connection
  • Intel® GbE LAN for WOL and PXE Support
  • GIGABYTE UEFI DualBIOS™ Technology
  • Small chassis 193 mm(L) x 153 mm(W) x 67 mm(H) with 12~19/24V DC-In Power Design
  • Compatible with Intel CPU BOX Cooler
  • Support Intel® Small Business Basics
    • * Wireless module inclusion may vary based on local distribution.

* Self Assembly Required
View Detail of GA-H110MSTX-HD3-ZK
GA-H110MSTX-HD3(1.0)
GA-H110MSTX-HD3

  • Supports 7th / 6th Generation Intel® Core™ Processors
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • Features USB 3.0 with USB Type-C™ Support
  • 1 x RS232 COM Port Support
  • M.2 Socket 1 Interface for WIFI+BT Module Support
  • M.2 Socket 3 Interface for SATA Mode SSD Support
  • Rear Panel DisplayPort, HDMI 1.4, D-Sub Ports for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Intel® GbE LAN for WOL and PXE Support
  • GIGABYTE UEFI DualBIOS™ Technology
  • Mini-STX 147x140mm Form Factor with 12~19V DC-In Power Design
  • Support Intel® Small Business Basics
  • Compatible with GIGABYTE Mini STX Chassis
View Detail of GA-H110MSTX-HD3
GA-H110TN-E (rev. 1.0)
GA-H110TN-E

  • Supports 7th / 6th Generation Intel® Core™ Processors
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
  • Mini-PCIe Dual Purpose Slot for mSATA SSD Support
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 1.4 Ports for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Intel® GbE LAN for WOL and PXE Support
  • Features 4 USB 3.0 and 4 USB 2.0 Ports
  • GIGABYTE UEFI DualBIOS™ Technology
  • Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
View Detail of GA-H110TN-E
GA-H110TN-M (rev. 1.0)
GA-H110TN-M

  • Supports 7th / 6th Generation Intel® Core™ Processors
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • 2 x RS232/422/485, Digital I/O 4-in/4-out
  • Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
  • Mini-PCIe Dual Purpose Slot for mSATA SSD Support
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 1.4 Ports & D-sub Header for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Intel® GbE LAN for WOL and PXE Support
  • Features 4 USB 3.0 and 4 USB 2.0 Ports
  • GIGABYTE UEFI DualBIOS™ Technology
  • Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
View Detail of GA-H110TN-M
GA-Q170TN-T20-GSM PLUS(1.0)
GA-Q170TN-T20-GSM PLUS

  • Supports 7th / 6th Generation Intel® Core™ Processors
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • 2 x RS232 / 422 / 485, 2 x RS232, Digital I/O 4-in/4-out
  • Mini-PCIe Slot for Full / Half-Height WIFI Card Support
  • Mini-PCIe Dual Purpose Slot for mSATA SSD Support
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 1.4 Ports & D-Sub Header for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Dual Intel® GbE LAN for WOL and PXE Support
  • Features 4 USB 3.0 and 4 USB 2.0 Ports
  • GIGABYTE UEFI BIOS Technology
  • Thin Mini-ITX 170x170mm Form Factor with 12~24V DC-In Power Design
  • Intel® vPro Technology Support
  • TPM 2.0 onboard
View Detail of GA-Q170TN-T20-GSM PLUS
GA-IMB370TN(1.0)
GA-IMB370TN
  • Supports 9th and 8th Generation Intel® Core™ Processors up to 65W
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
  • M.2 Socket 1 for PCIe WIFI co-lay with CNVI Hybird E key WIFI
  • M.2 Socket 2260/80 Storage support PCIe/SATA Mode
  • Mini-PCIe Slot Full size Support mSATA/PCIe mode
  • VGA Header for legacy Monitor
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 2.0 Ports & D-sub Header for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Dual Intel® GbE LAN for WOL and PXE Support
  • 4 USB 3.0 and 4 USB 2.0 Ports, USB 3.0 support OTG function
  • OP: 0~60 degree
  • Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
  • Compatible with GIGABYTE Thin mini ITX Chassis


    • * Datasheet Download
View Detail of GA-IMB370TN
GA-H310TN(1.0)
GA-H310TN
  • Socket LGA1151 for Intel Core i9/i7/i5/i3/Pentium/Celeron (Coffee lake-S)
  • Intel® Gen10 Intel Graphics DX 11/12, OGL4.3/4.4
  • Supports Single Channel DDR4 2133/2400MHz, 1 x SO-DIMM, up to 16GB system memory
  • 1 x HDMI, 1 x VGA, 1 x Dual Channel 24-bit LVDS
  • 4 x USB 3.0, 4 x USB 2.0, 2 x SATA3
  • 1 x M.2 wifi, 1 x M.2 SSD
  • Gigabit LAN : 1 x Realtek Lan
  • 1 x TPM 2.0 IC onboard
  • 19 V DC-in
  • Compatible with GIGABYTE Thin mini ITX Chassis


    • * Datasheet Download
View Detail of GA-H310TN
IMB310TN(1.0)
GA-IMB310TN
  • Supports 9th and 8th Generation Intel® Core™ Processors up to 65W
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
  • M.2 Socket 1 for PCIe WIFI co-lay with CNVI Hybird E key WIFI
  • M.2 Socket 2260/80 Storage support PCIe/SATA Mode
  • Mini-PCIe Slot Full size Support mSATA/PCIe mode
  • VGA Header for legacy Monitor
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 2.0 Ports & D-sub Header for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Dual Intel® GbE LAN for WOL and PXE Support
  • 4 USB 3.0 and 4 USB 2.0 Ports, USB 3.0 support OTG function
  • OP 0~60 degree
  • Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
  • Compatible with GIGABYTE Thin mini ITX Chassis


    • * Datasheet Download
View Detail of GA-IMB310TN
GA-H110TN (rev. 1.0)
GA-H110TN

  • Supports 7th / 6th Generation Intel® Core™ Processors
  • Dual Channel DDR4 SO-DIMM, 2 DIMMs
  • 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
  • Mini-PCIe Slot for Full/ Half-Height WIFI Card Support
  • Mini-PCIe Dual Purpose Slot for mSATA SSD Support
  • LVDS Header for System Integrated Flat Panel Display Support
  • Rear Panel DisplayPort, HDMI 1.4 Ports & D-sub Header for Multi-Display Connection
  • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
  • Dual Intel® GbE LAN for WOL and PXE Support
  • Features 4 USB 3.0 and 4 USB 2.0 Ports
  • GIGABYTE UEFI DualBIOS™ Technology
  • Thin Mini-ITX 170x170mm Form Factor with 12/19~24V DC-In Power Design
  • Compatible with GIGABYTE Thin mini ITX Chassis
View Detail of GA-H110TN
❮
❯
