Specifications
CPU
- Single Intel® Pentium Prescott LGA 775 processor with L2 cache
- Supports 800MHz/Socket 775
Chipset
- Intel® MCH E7221
- Intel® 6702 PXH-V
- Intel® ICH6R
LAN
- Build in dual Intel® 82541PI Gigabit Ethernet
- Adapter Fault Tolerance (AFT)
- Adaptive Load Balancing (ALB)
Video
- Built-In ATI® Rage XL video chip with 8MB memory
RAID
- Raid 0/1 by Intel ®ICH6R I/O controller (Adaptec SATA HostRaid)
Expansion Slots
- 1 PCI-Express X4 Slot
- 2 PCI-X 64-bit/66~100MHz Slots
- 3 PCI 32bit/33MHz Slots
Rear I/O
- 2 x PS/2
- 1 x Parallel Port
- 2 x USB 2.0
- 1 x COM
- 1 x VGA
- 2 x LAN RJ45
