Specifications
CPU
- Supports Dual Intel® Xeon CPUs
- Supports 533/socket604
Chipset
- Intel® 875P (Memory Controller Hub)
- Intel® 6300ESB
LAN
- Build in Intel® CSA 82547GI Gigabit Ethernet controller
- Wake On LAN (WOL)
- ASF 1.0& 2.0 support
- Compliant with PCI power management v1.1/ACPI v2.0
Audio
- Realtek ALC658 UAJ CODEC
- Support Jack-Sensing / Line Out / 2 front speaker / Line In / 2 rear speaker(by s/w switch) / Mic In / center& subwoofer(by s/w switch) / SPDIF Out /SPDIF In / CD_In
- Surround Back speaker (by opt ional Surround-Kit)
SATA
- 2 x SATA ports
IDE / SCSI
- Dual ATA 100 IDE channels
Expansion Slots
- 2 x PCI-X 66 MHz
- 3 x PCI 32/33 MHz
- 1 AGP 8X pro slot
Rear I/O
- 2 x PS/2 (Keyboard and Mouse Connectors)
- 4 x USB 2.0 port
- 2 x COM (1xRear, 1xBy.Cable)
- 1 x LPT
- 2 x LAN RJ45
