GA-6FXSV2Legacy | Firmware updates supported
Intel 3420 chipset
- ATX form factor easy to find suitable chassis.
- Entry server board with essential server-class features.
- Support one Intel Xeon processor 3400 series.
- Up to 6 DIMMs of registered DDR3 or 4 DIMMs ECC unbuffered DDR3 memory.
- Well-rounded expansion: one PCIe 2.0 x16, one PCIe 2.0 x8, one PCIe 2.0 x4, one PCIe 2.0 x1, and one PCI.
- Onboard ServerEngines Pilot II providing secure IP-based remote server management.
- Specifications
- Support
- Related Resources
Specifications
Form Factor
- ATX (12” x 9.6”)
CPU
- Single Intel Xeon processor 3400 series
Chipset
- Intel 3420 chipset
Memory
- 6 DDR3 DIMM sockets support registered (Lynnfield)
- 4 DDR3 DIMM sockets support ECC unbuffered (Clarkdale)
- 2 channel native 1066/ 1333MHz
LAN
- 2 Gigabit LAN (Intel 82578DM + Intel 82574L)
Video
- Matrox G200e (ServerEngines Pilot II)
SATA
- 6 ports SATA 3Gbps via Intel 3420
RAID
- Intel SW RAID 0/ 1/ 5/ 10
Expansion Slots
- 1 PCI Express 2.0 x16
- 1 PCI Express 2.0 x8
- 1 PCI Express 2.0 x4
- 1 PCI Express 2.0 x1 (x8 mechanical)
- 1 PCI
Board Management
- ServerEngines Pilot II (IPMI 2.0) + iKVM
Reference Numbers
- 9M6FXSV2NR-00
