GA-7TESH2-RHLegacy | Software updates supported
- Support dual Intel Xeon 5600/ 5500 processors with integrated 3 channel DDR3 memory controller and QuickPath Interconnect.
- Advanced memory RAS for higher reliability and stability.
- Advanced virtualization technology for ultimate utilization.
- Maximum memory capacity upto 96GB Registered DDR3 800/ 1066/ 1333.
- Onboard ServerEngines Pilot II providing secure IP-based remote server management.
- Dual GbE supporting I/OAT with Direct Cache Access, VMDq, IPv6 Offloading and Linksec.
- Specifications
- Support
- Related Resources
Specifications
Form Factor
- ETAX(12” x 13”)
CPU
- Dual Intel Xeon 5600/ 5500 Processor
Chipset
- Intel 5520 IOH + Intel ICH10R
Video
- Integrated in ServerEngines Pilot II (Matrox 200e)
SATA
- SATA-2 x6 ports( ICH10R, LSI S/W RAID 0,1, 10)
Expansion Slots
- 1 x PCI-e x16(@ Gen 2 x16 bus)
- 1 x PCI-e x8(@ Gen 2 x8 bus)
- 1 x PCI-e x8(@ Gen 2 x4 bus)
- 1 x PCI-e x8(@ Gen 1 x4 bus)
- 1 x PCI-32
Rear I/O
- UID button W/LED
- VGA
- COM
- 4 x USB
- 2 x RJ45
- 1 x RJ45 (Management)
- PS/2
Board Management
- ServerEngines Pilot II (IPMI 2.0) +i KVM
