E251-U70

End of Support

Rev. 100

Edge Server - 2nd Gen Intel^® Xeon^® Scalable - 2U UP 1 x PCIe Gen3 GPU

AI Visual Computing Edge Hybrid/Private Cloud Server AI Inference

Supports up to 1 x Dual slot Gen3 GPU
Single 2nd Gen Intel^® Xeon^® Scalable Processors
6-Channel DDR4 RDIMM/LRDIMM, 8 x DIMMs
Supports Intel^® Optane™ DC Persistent Memory
2 x 1Gb/s LAN ports via Intel^® I210-AT
6 x 2.5" SATA/SAS hot-swap bays
1 x M.2 slot with PCIe Gen3 x4 interface
1 x FHFL PCIe Gen3 x16 slot for GPUs
1 x FHFL PCIe Gen3 x16 slot for LAN cards
Dual 800W 80 PLUS Platinum redundant power supply

Save

제품 사양

Dimensions (WxHxD, mm)

2U
439 x 86 x 449

Motherboard

MU71-SU0

CPU

2nd Generation Intel^® Xeon^® Scalable Processors
Single processor
CPU TDP up to 205W

Socket

1 x LGA 3647
Socket P

Chipset

Intel^® C621

Memory

8 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
Supports Intel^® Optane™ DC Persistent Memory (DCPMM)
1.2V modules: 2933(1DPC)/2666/2400/2133 MT/s

LAN

Front side:
2 x 1Gb/s LAN ports (2 x Intel^®I210-AT)
1 x 10/100/1000 Mbps Management LAN

Video

Integrated in Aspeed^®AST2500
- 1 x VGA port

Storage

Front side:
6 x 2.5" SATA/SAS hot-swappable bays

SAS card is required for SAS devices support

SAS

Depends on SAS add-in cards

RAID

Intel^® SATA RAID 0/1/10/5

Expansion Slots

1 x PCIe x16 (Gen3 x16) FHFL slot, for GPUs
1 x PCIe x16 (Gen3 x16) FHFL slot, for LAN cards

Note: Signal from SLOT6 with PCIe switch (PEX8747).

1 x M.2 slot:
- M-key
- PCIe Gen3 x4
- Supports 2280 cards

Internal I/O

1 x TPM header
1 x VROC connector

Front I/O

5 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED

Front Panel:
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

Rear I/O

N/A

Backplane Board

Speed and bandwidth:
SATA 6Gb/s or SAS 12Gb/s

TPM

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply^[#1]

Dual 800W 80 PLUS Platinum redundant power supply

System Management

Aspeed^® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
JAVA Based Serial Over LAN
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage/Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP/AD/RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.5.0 or later
Citrix Hypervisor 8.0.0 or later

Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP3 or later
SUSE Linux Enterprise Server 15 or later

Ubuntu 18.04 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 6.0 Update3 or later
VMware ESXi 6.5 Update2 or later
VMware ESXi 6.7 Update1 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later

Windows Server 2012 R2 with Update
Windows Server 2016
Windows Server 2019

OS Certifications

Windows Server 2019

System Fans

4 x 80x80x38mm, 2-ball

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Note: Please contact Technical Support for more information about optimized GPU system operating temperature.

Packaging Dimensions

867 x 588 x 276 mm

Packaging Content

1 x E251-U70
1 x CPU heatsink
1 x Rail kit
2 x Non-Fabric CPU carriers

Part Numbers

- Barebone package: 6NE251U70MR-00-1*
- Motherboard: 9MU71SU0NR-00
- Rail kit: 25HB2-3A0205-C0R
- CPU heatsink: 25ST1-353105-T1R
- Riser card - CRSE520: 9CRSE520NR-00
- SAS cable for CRA4448: 25CFI-650720-A4R

[#1] Power cords are not included with server packages. Customers are responsible for selecting appropriate power cords from the optional accessories or contacting sales for customization.

[#2] All materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at any time without prior notice.

[#3] Advertised performance is based on maximum theoretical values as specified by the respective chipset vendors or standards organizations. Actual performance may vary depending on system configuration.

[#4] All trademarks and logos are the property of their respective owners.
