- For SI Only
- Dual Intel® Xeon™ at FSB 667/1066/1333MHz/LGA771
- Intel®5000X/Intel® 6321ESB/Intel 6702 PXH-V chipset
- Max 32GB Fully Buffered DIMMs with 533/667MHz
Two PCI-E x16 Slots(One by 16 and another one by 8) - Two PCI-X 64-bit/133MHz/3.3V slots (compliant to PCI-X rev 1.0)
- One PCI-X 64-bit/66/100MHz/3.3V slot (compliant to PCI-X rev 1.0)
- LSI® PCI-X 1068 SAS controller/8 Ports
- LSI® Host RAID 0, 1, 10
- LSI® Software RAID 0, 1, 10, 5 (RAID 5 is optional, reserved for ibutton)
- LSI® Hardware RAID 0, 1, 10, 5 (RAID 5 is optional, via ZCR slot)
- Intel® SATA RAID 0, 1, 10, 5 (RAID 5 is optional, reserved for ibutton/Windows only)
- Dual Intel®Gigabit Ethernet controllers
- EATX Form Factor(12”W * 13”D)
Specifications
CPU
- Dual-Core Intel® Xeon™ (Dempsey/Woodcrest) processors
- Supports 667/1066/1333MHz/Socket LGA771
Chipset
- Intel®5000X
- Intel®6321ESB
LAN
- Build in Intel® 6321ESB supports dual Gigabit Ethernet ports
Audio
- Realtek® ALC883
SAS
- LSI® SAS1068 SAS Controller
SATA
- Built in Intel®6321ESB with SATA RAID 0,1,10
RAID
- Intel® 6321ESB with SATA RAID 0,1,10
- LSI®SAS1068 supports 8 independant SAS 3.0 Gb/s with Host RAID 0,1,10
Expansion Slots
- 1 x PCI-E slot by x16
- 1 x PCI-E slot by x8 ( in x16 socket)
- 2 x PCI-X slot support 64/133MHz
- 1 x PCI slot supports 32/33MHz
Internal I/O
- 1 x ATA-100 connector
- 1 x Floppy connector
- 2 x IEEE1394 connector
- 1 x SPDIF In pin header
- 6 x Serial ATA 3Gb/s connector
Rear I/O
- 2 x PS/2
- 8 x USB 2.0 (4 by cable)
- 1 x Parallel
- 2 x COM (2 by cable)
- 2 x LAN RJ45
- 6 x Audio jacks
- 1 x Optical SPDIF OUT
- 1 x Coaxial SPDIF OUT
