• Panel Driver Power Selectable
  • Back Light Module Power Selectable
  • Wide Range Voltage Input
  • PCI Express x4 Slot

  • GIGABYTE Thin Mini-ITX Motherboards
    GIGABYTE Thin-Mini-ITX motherboards are the ideal platform for today’s All-in-One, small form factor and slim profile PCs. Offering a full featured PC experience in a minimal device footprint, GIGABYTE Thin Mini-ITX motherboards are 43% thinner than traditional Mini-ITX designs. Complying with the latest Thin Mini-ITX guidelines, GIGABYTE Thin Mini-ITX motherboards offer additional flexibility making them suited to broad range of innovative PC designs.
  • Selectable Panel Power Driver
    GIGABYTE Thin Mini-ITX motherboards feature a selectable power driver allowing for both 3.3v and 5v configurations. This brings additional flexibility for LVDS panels that require both 3.3v and 5v drivers. Voltage settings are configured via an onboard jumper.
  • Selectable Back Light Power Module
    GIGABYTE Thin Mini-ITX motherboards offer flexible backlight power delivery with both 12v and 19v options available via onboard jumpers. This enhances compatibility with the wide range of backlit displays available today.
  • Wide Range Voltage Input
    Offering additional flexibility for system DC voltage input, GIGABYTE Thin Mini-ITX motherboards offer a broad voltage range of 12v to 19v, eliminating compatibility issues with many traditional IPC designs.
    * GIGABYTE recommends 180W power adapters for processors above 84W TDP. Processors with a TDP lower than 84W, may use 150W power adapters.
    * Power adapters connector dimension: 7.4 x 5.1mm, 180W = 19V / 9.47A , 150W = 19V / 7.89A.
  • PCI Express x4 Expansion Slot
    GIGABYTE Thin Mini-ITX motherboards are equipped with a x4 PCI Express expansion slot providing up to 25W of power and easy integration of TV tuner, video capture or RAID cards with a compatible riser card.
  • PCI Express Gen.3 지원


    GIGABYTE 메인보드는 PCI Express 3.0전송 기술을 지원하여, 차세대 PCI Express 3.0 그래 픽카드의 대역폭을 최대화했으며 익스트림 그래픽 성능을 제공한다.
    * PCIe Gen. 3 기능은 CPU 및 그래픽 카드의 지원에 따라 다를 수 있다.
  • Intel® Smart Connect 기술
    Intel® Smart Connect 기술은 시스템이 대기 상태에 있어도 메일, 자주 사용하는 어플리케이션, 소셜 네트워크가 자동 업그레이드 되도록 한다. PC 앞에 굳이 앉아 있지 않아도 최신 세계 뉴스와 친구의 소식을 접할 수 있다. 'ON' 버튼만 클릭하면 자동 업그레이드되어 최신 트렌드에서 뒤떨어지지 않는다.
  • Onboard mSATA Support
    GIGABYTE 6 series motherboards feature an onboard mSATA slot allowing users to easily take advantage of advanced SSD-based technologies like Intel® Rapid Start. Mounting an affordable, low capacity mSATA SSD directly onto your motherboard can enhance your PC's performance with better overall desktop responsiveness, faster boot times and faster system resume from 'Suspend to Disk' and 'Standby' modes.
  • Intel® Quick Sync 2.0
    신세대 Intel® Quick Sync 2.0
    미디어 인코딩 기술이 빨라져 집에 있든 온라인에 있든 영상물을 빠르게 제작, 편집하고 실시간으로 감상할 수 있다. 별도의 하드웨어를 추가 구입하지 않아도 된다. 3세대 Intel® 코어 프로세서의 Intel® Quick Sync 2.0 기술이 온보드된 신세대 하드웨어 가속기술로 여러 시간을 들여야 완성할 수 있었던 일을 몇 분 안에 손쉽게 마칠 수 있게 되었다.
  • 50,000 Hours Solid Capacitors
    GIGABYTE Ultra Durable motherboards are equipped with solid capacitors. With an average lifespan of 50,000 hours, these solid capacitors provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games.


    * 50000 hours of work time is calculated at 85℃ ambient temperature.
  • DirectX 11 동영상 기술 지원
    DirectX 11 동영상 기술 지원
    프로그램 DirectX 11는 Eye-popping3D 비주얼을 제공하고 최신 멀티코어 프로세서를 사용하여 복잡한 세이딩(shading) 및 테셀레이션 (Tessellation)을 제공하여 최신 PC게임 비주얼에 대한 니즈를 충족해 준다.
  • DisplayPort 디스플레이 인터페이스 지원
    기가바이트의 메인보드에는 차세대 그래픽 디스플레이 포트가 탑재되어, 10.8 Gbps 광대역을 통해 자연색을 표현해주며 모니터의 화면주사율(refresh rate)을 빠르게 하여 컬러 심도를 최대로 올려준다.
  • HDMI™-The Next Generation Multimedia Interface
    HDMI™ is a High-Definition Multimedia Interface which provides up to 2.5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.

* HDMI, HDMI High-Definition Multimedia Interface(고화질멀티미디어인터페이스), HDMI 트레이드드레스및 HDMI 로고라는용어는 HDMI Licensing Administrator, Inc.의상표또는등록상표입니다.
* 사이트에서 제공되는 모든 자료는 참조용일 뿐입니다. 기가바이트는 사이트의 자료를 사전 통지없이 언제든지 수정할 권리를 지닙니다.
* 모든 상표와 로고는 해당 소유자의 자산입니다.
* PC의 표준 아키텍쳐에 의해, 메모리의 특정 부분이 시스템에 사용되어 실제 메모리 크기는 표준보다 적게 표시될 수 있습니다.
